Airport Queuing Conveyor
Sketch Map of Airport Queuing Conveyor
As part of the check-in and ticketing system, the queuing conveyor is the front-end equipment of the baggage handling system. The passengers will put the baggage on the weighing/labeling conveyor to measure its weight and size. If the baggage is normal, the operator will label it and have it sent to the queue belt conveyor. At the end of the queue belt conveyor, baggage will automatically stop on the queue belt conveyor to wait for the baggage window. When the baggage window of the collection conveyor appears, the queuing conveyor will automatically start up and deliver the baggage to the collection conveyor.
Main Technical parameters of airport queuing conveyor
|
Length of the conveyor(L) |
1200mm~3000mm |
Static load |
150kg/m |
Side plate |
GB304 |
|
Height of the belt surface(H1) |
330m~400mm |
Dynamic load |
50kg/m |
Lateral cover plate |
GB304 |
|
Height of the whole machine(H2) |
400mm~650mm |
Head roller |
Φ60mm |
Tuckle Plate |
Q235
|
Belt width(W1) |
450mm~680mm |
Tail roller |
Φ60mm |
Slinding bed board |
Q235 |
Side placte spacing(W2) |
480mm~720mm |
Tension roller |
Φ60mm |
Fittings |
Q235 |
Conveyor width(W3) |
600mm~840mm |
Electric roller |
Φ113mm |
Plug pin |
Q235 |
Speed |
21m/min~30m/min |
Belt |
Anit-skid, antiflaming, antistatic |
||
Noise |
≤65dB(A) (Ground clearance of 1m,1m away from the sound source, environmental noise 50 dB(A)) |
||||
Optional size of queuing conveyor
Belt width
450mm,500mm,550mm,600mm,650mm,680mm and so on as you like
Conveyor length
1200mm,1300mm,1400m,1500m and so on
