1XLAN 3G EVDO Industrial M2m Router with WiFi for Vending Machine

Specifications

Wireless Routers
1. CDMA20001X EV-DO 3G networks
2 industrial design and 1 RJ45 Ethernet port
3. 1xLan EVDO router

1XLAN 3G EVDO IndustrialM2m Route

Caimore industrial 1XLAN 3G EVDO IndustrialM2m Route (Type: CM520-81E ), is wireless router by using CDMA20001XEV-DO 3G networks, with industrial design and one RJ45 Ethernet port.









Wireless parameters:



Item	Content
Wireless module	use industrial wireless module
Standards and frequency bands	Support  IS-95 A/B, CDMA2000 1XrTT, and 1X EV-DO(Revision 0 and A) 800Mhz ,Optional 800/1900Mhz or 450Mhz
Coding scheme	IS-95 A/B, CDMA2000 1XrTT,and 1X EV-DO mode
Communication bandwidth	Download 3.1Mbps, Upload 1.8Mbps
Transmit power	<23dBm
Receiver sensitivity	<-107dBm
Function support	Support data, voice, SMS and fax





Interface Type:



Item	Content
Ethernet port	1xLAN(One 10/100 Base-T Ethernet ports), Ethernet IEEE 802-3, 802-2; built-in 1.5KV magnetic isolation protection
Serial ports	1 RS232 serial port or 1 RS485 interface (supports RS422/TTL) Bytesize: 7,8 bit Stopbits: 1, 2-bit Parity: no parity, odd parity, even parity, SPACE and MARK parity Baudrate: 110bps ~ 230400bps Flow Control
Indicator	With “POWER”, connecting “Link / ACT”, communication “COMM” and “ONLINE” indicator LED
Antenna Interface	Standard SMA female interface, 50 ohm
UIM interface	1.8V/3V/5V standard putter user card interface, built-in 15KV ESD protection
Voice Interface	Standard headset interface (requires software)
Power Interface	Standard 3-pin power jack



II product characteristics

Industrial Design

Stable and reliable

 Powerful Function
1.Support Ethernet data communication and packet forwarding, also supports serial port TCP / UDP

transparent data transmission or serial configuration
2.Support VPN tunnel, including PPTP, MPPE, L2TP, GRE and IPSEC
3.Intelligent anti-dropped, support online testing, online maintenance, automatic redial, router is always on-line
4.Support IPTABLES firewall, packet filtering
5.support Regular on-line offline functionality
6.Support a variety of trigger and offline modes
7.Support dynamic routing and static routing, RIPv1, RIPv2, OSPF, BGP, NDSP, IRMP, SNSP, IGMP,

DVMRP, PIM-SM/DM
8.Support multiple protocols: TCP / IP, UDP, ICMP, SMTP, HTTP, POP3, OICQ, TELNET, FTP, etc.
9.Support DHCP / DHCPD functionality
10.Supports NAT port mapping function, such as SNAT, DNAT
11.Support DDNS(Dynamic Domain Name Server): support ORAY, 88IP, and DYNDNS domain name

service provider
12.Support DMZ
13.Support the APN / VPDN network
14.Convenient WEB configuration, Remote WEB Management
15.Support WEB configuration save and restore to achieve the rapid deployment parameters backup and

batch of equipment
16.Support telnet management, user-friendly console shell interactive environment
17.Support multiple terminals sharing router ppp wan
18.Support multiple wireless dial-up mode: automatically assigned, specify the IP, specify local and remote IP
19.Support as a PPP server, multiple authentication methods, support mutual authentication
20.Easy to use COM and SYSLOG System diagnostics, debugging
21.Support Serial port local software upgrades
22.Supports TFTP remote software upgrade
23.Support real-time clock
24.Support both LINUX and WINDOWS operating systems
