4XLAN 3G EVDO 4-PORT-cable Routers1. Supporting VPN and PPTP, MPPE, L2TP, GRE and IPSEC
2 Support IPTABLES firewall, packet
4XLAN 3G EVDO 4-PORT-cable Routers
Caimore Wireless 3G EVDO Router (Type: CM520-82E ) is EVDO router with industrial design and 4 RJ45 Ethernet port.
Produce interface diagram
Accessories photos
I. Wireless parameters:
Item |
Content |
Wireless module |
use industrial wireless module |
Standards and frequency bands |
Support IS-95 A/B, CDMA2000 1XrTT, |
Coding scheme |
IS-95 A/B, CDMA2000 1XrTT,and 1X EV-DO mode |
Communication bandwidth |
Download 3.1Mbps, Upload 1.8Mbps |
Transmit power |
<23dBm |
Receiver sensitivity |
<-107dBm |
Function support |
Support data, voice, SMS and fax |
II Interface Type:
Item |
Content |
Ethernet port |
1xLAN(One 10/100 Base-T Ethernet ports), Ethernet IEEE 802-3, 802-2; built-in 1.5KV magnetic isolation protection |
Serial ports |
1 RS232 serial port or 1 RS485 interface (supports RS422/TTL) software flow control |
Indicator |
With “POWER”, connecting “Link / ACT”, communication “COMM” and “ONLINE” indicator LED |
Antenna Interface |
Standard SMA female interface, 50 ohm; optional 3M/5M/10M/15M antenna extension cable, meet the different needs of customers |
UIM interface |
1.8V/3V/5V standard putter user card interface, built-in 15KV ESD protection |
Voice Interface |
Standard headset interface (requires software) |
Power Interface |
Standard 3-pin power jack |
III product characteristics
1.Supports Ethernet data communication and packet forwarding, also supports serial port
TCP / UDP transparent data transmission or serial configuration
2.Support VPN tunnel, including PPTP, MPPE, L2TP, GRE and IPSEC
3.Intelligent anti-dropped, support online testing, online maintenance, automatic redial, router is always on-line
4.Support IPTABLES firewall, packet filtering
5.support Regular on-line offline functionality
6.Support a variety of trigger and offline modes
7.Support dynamic routing and static routing
8.Support multiple protocols:
9.Support DHCP / DHCPD functionality
10.Supports NAT port mapping function
11.Support DDNS(Dynamic Domain Name Server)
12.Support DMZ
13.Support the APN / VPDN network
14.Convenient WEB configuration, Remote WEB Management
15.Support WEB configuration save and restore to achieve the rapid deployment parameters backup and
batch of equipment
16.Support telnet management
17.Support multiple terminals sharing router ppp wan
18.Support multiple wireless dial-up mode
19.Support as a PPP server, multiple authentication methods, support mutual authentication
20.Easy to use COM and SYSLOG System diagnostics, debugging
21.Support Serial port local software upgrades
22.Supports TFTP remote software upgrade
23.Support real-time clock
24.Support both LINUX and WINDOWS operating systems
