Help CenterAutomatic Pin Insertion Machine
Related Products
-
ZX-680S Full Automatic High-speed Pin Insertion MachieUS$ 38,500 - 53,900MOQ: 1 Set -
ZX-650S Pin Insertion Machine for PCB AssemblyUS$ 43,999 - 54,999MOQ: 1 Set
-
ZX-650 Full Automatic Special-shape Piece Inserting MachineUS$ 59,999 - 79,999MOQ: 1 Set
-
ZX-600 Full Automatic Four Head Riveting MachineUS$ 27,000 - 43,999MOQ: 1 Set
-
BCM Press Fit Pin Insertion MachineUS$ 100,000 - 1,000,000MOQ: 1 Set
Specification:
Overall dimension:2250*1300*1600mm Weight:1000KG
Air: 6+/-0.5kg/cm2(air consumption: 656N/min) Power:AC220V,single-phase50/60HZ,1.4KW
Noise:80dB Operating enviroment5-40℃ Humidity:10-90%RH(it can be used as long as there are no crystal beads in the air) Requirements for the surronding enviroment:no corrossive gas
Movement dimension of the workbench:X680mm, Y370mm,Multi-direction X580mm,Y370mm Bilatery.
Movement speed of workbench:22.5m/min PCB electric circuit board:500*350Max
Flow direction of PCB:L-R,R-L
Inserting direction: 0, 90, 180,270 degrees or multi-angle.
Plugging speed:140-220PCS/min
External communication funtion: by RS-485 interface.
Installation time of electric circuit board:4s Component iserted:all kinds of conventional and special-shape end pieces and circled pin end pieces.
Quantity of inserting heads:1-3(based as required)
Hole correction mode:CCD HD indusrial camera angle system
Display system:17inch color LCD
