Home > Packaging & Printing > Packing Machinery > Packing Line > ZX-600 Full Automatic Four Head Riveting Machine
ZX-600 Full Automatic Four Head Riveting Machine
US$ 27,000 - 43,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
YICHUAN MACHINE
Payment & Shipping
Payment Methods:
Port of Shipment:
SEKOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BCM Press Fit Pin Insertion MachineUS$ 100,000 - 1,000,000MOQ: 1 Set -
Pin Insertion Machine of Automotive Fuse AssemblyUS$ 100,000 - 1,000,000MOQ: 1 Set
-
Terminal Inserted Machine of PCB AssemblyUS$ 100,000 - 1,000,000MOQ: 1 Set
-
Fuse Automatic Stitching MachineUS$ 53,999 - 76,999MOQ: 1 Set
-
Automatic Pin Insertion MachineUS$ 38,000 - 76,000MOQ: 1 Set
Condition
New
Place of Origin
Guangdong, China
Brand Name
YICHUAN MACHINE
Model Number
ZX-600
Voltage
220V 50/60Hz
Power(W)
3KW
Weight
350KG
Dimension(L*W*H)
Packing Size L2200*W1800*H2000mm
Certification
ISO9001
Warranty
1 Year
After-sales Service Provided
Overseas third-party support available
ZX-600 Full Automatic High-speed Riveting Machine
Function
This equipment can be used to all kinds of specifications of bulk rivet by vibration dist sorting and then transported to the plug-in head, by inserting head of automatic riveting accurate inserted into circuit board and open all kinds of flower shape make it out out with the adhesion strength function equipment.
Specification:
- Overall dimension:2250*1300*1600mm
- Weight:1000KG
- Air: 6+/-0.5kg/cm2ï¼Ë†air consumption: 656N/minï¼â€°
- Power:AC220V,single-phase50/60HZ,1.4KW
- Noise:80dB
- Operating enviroment 5-40
- Humidity:10-90%RH(it can be used as long as there are no crystal beads in the air)
- Requirements for the surrounding environment:no corrossive gas
- Movement dimension of the workbench:X680mm, Y370mm,Multi-direction X580mm,Y370mm Bilatery.
- Movement speed of workbench:22.5m/min
- Rotary table of the workbench
- PCB electric circuit board:500*350Max
- Plugging speed:200PCS/min
- Installation time of electric circuit board:4s
- Component inserted:1.6-3.5mm common rivets, long rivets and lace rivet
- Q'ty of plugs:1-4plugs based on the requirements
- Hole correction mode:by the angle system of the machine
- Computer control system:Intel Corei3 CPU Windows operation system
- Display system:17inch color LCD
- Feeding system:vibrating large feeding system
