High speed T-shirt paper Bags Flexo Printing Machine Roll to Roll
The main parameters:
1, Machine Model: 1200mm
2, printed material: Non-woven
3, the maximum printing width: 1160mm
4, the maximum printing length :100-940mm
5, printing speed :10-50m / min
6, the thickness of the plate (including a double-sided adhesive): 2.38mm
Second: Discharge part:
1, roll length: 1200mm
2, effective printing roll length: 1200mm
3, roll core diameter 76mm
4,Discharge maximum diameter: 1000mm
5,Discharge: magnetic auto tension unwinding automatic correction
Third: Traction part:
1,Traction components: chrome roll roller
2, groups: Group 2
Fourth: Printed part:
1, printing Composition: chrome-plated roller plate roller anilox roller roller
2, the perimeter of the plate roller :100-350mm
3, printing plate: resin offset
4 Transmission: gear driven
5,Printing chromatic: 360 degree rotation
6 adjustment: manual
7, the ups and downs Adjustment: Manual
Fifth: Heating and drying part
1, the heating and drying way: first hairdryer reheating the
2, heating zones: 2 color: 4
3, heating power: 1200mm type: 2.2kw
4, auxiliary drying length: 1 m
5, fans: 2
6, the fan power: 1200mm: 2 * 0.75kw
Six: motor parts:
1, Main motor: 2-color 1200mm: 2.2kw
2, Shipped the ink motor: 2 color: 1200mm: 0.75kw
3, host inverter is used to control speed
Seven: the winding section
1, roll length: 1200mm
2, effective roll length: 1200mm
3, roll core diameter: 76mm
4,Discharge maximum diameter: 1000mm
5, winding friction rewinding
