Rotary Type Rain Boots Automatic Injection Moulding Machine

Rotary Type Rain Boots Automatic Injection Moulding Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Taiwan, China
Brand Name:
kou yi
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Taiwan, China
Brand Name kou yi
Model Number NSK-375
After-sales Service Provided Engineers available to service machinery overseas
Rotary Type Rain Boots Automatic Injection Moulding Machine
NSK-375
Rain Boots  Injection Machine
Safety Shoes Machinery



The molds of the former vertical injection molding machine for rain boots was liable to wear down.The quality of rain boots was not good,and the machine was not easy to operate.Therefore,we imported the latest technique to develop the "Auto rotary injection molding machine for rain boots".The molds of NSK-375 can open and close automatically,which can save manpower and make it easy to operate the machine.With the "Wind pressure auto molding system",the operators can easily remove finished products from the molds without damaging the lasts so that the molds can last longer.

The NSK-375 adopts direct-pressure injection which generates high pressure.It can produce boots of different sizes at the same time.The high clamping pressure ensures the quality of products.The machine can produce boots of different sizes or heights simultaneously,which reduces production time.Furthermore,the machine also can produce sandals by changing the molds.



Rotary Type Rain Boots Automatic Injection Moulding MachineRotary Type Rain Boots Automatic Injection Moulding MachineRotary Type Rain Boots Automatic Injection Moulding Machine



Product Character
  • The NSK-375 is the first machine with the photo-cell digital locating system in Taiwan. It is
        easy to accurately adjust the ejection quantity.

  • The machine is specially designed for producing rain boots. It is automatic, economical,
        efficient, and easy to operate.

  • The machine is run by a hydraulic system. The machine can adjust clamping pressure and
        can work at high speed.

  • The NSK-375 has eight(8)molds; freely select their usage; molds can be opened and closed
        manually or automatically.

  • Besides the 16"(45mm) rain boots, it can also produce pumps, slippers, and sandals.

  • With the "Wind pressure auto mold-opening device", the operators can remove the
        finished products from the molds without damaging the lasts. The molds can therefore
        last longer.

  • Two options for ejection quantity are available: a fixed quantity or full mold.

  • Powerful mold clamping prevents burrs.

  • Many different sizes of rain boots can be produced at the same time. Also sandals
        and rain boots can be produced simultaneously.

  • The machine is suitable for P.V.C.,T.P.R.,and N.B.R...etc.



Product Specifications
Item NSK-375-8M NSK-375-10M NSK-375-12M
Mould Station 8 10 12
Mould Available Space 600 x 690 x 188 600 x 690 x 188 500 x 700 x 188
Heater Volume 9 kw 9 kw 10 kw
Electric Motor 30 HP x 1
20 HP x 1
30 HP x 1
20 HP x 1
30 HP x 1
20 HP x 1
Mould Clamping Force 200 Tons(Max.) 200 Tons(Max.) 230 Tons(Max.)
Max. Ejecting Volume 1588 cm3/shot 1588 cm3/shot 1788 cm3/shot
Total Electricity Consumption 47 kw 48 kw 49 kw
Machine Dimension 6700 x 3120 x 2100 m/m 7200 x 3420 x 2100 m/m 7700 x 3650 x 2130 m/m
Machine Weight. 13,000kgs 15,000kgs 17,000kgs
