Single Colored Automatic Rotary Type Sole Jointing & Ejecting Molding Machine

Single Colored Automatic Rotary Type Sole Jointing & Ejecting Molding Machine photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
kou yi
Model Number:
NSK-294
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Brand Name kou yi
Model Number NSK-294
Place of Origin Taiwan, China
Automatic Yes
After-sales Service Provided Engineers available to service machinery overseas

Single Colored Automatic Rotary Type Sole Jointing & Ejecting Molding Machine NSK-294

Sole making machine



Product Description

The NSK-294 adopted the latest technology from Europe. The machine can fasten soles to vamps in one step to replace the previous complicated sole-joining process-gluing and sole attaching and pressing, it can also save manpower, reduce production cost and improve your productivity.

In addition, the NSK-294 only moves the ejector while the molds are fixed. Therefore, the machine is steady and has no bugs. The molds are operated by the independent lubrication system, which generates great clamping pressure and simplifies the structure of the machine. The operation and maintenance of this machine is much easier than the traditional European one.



Product Character

·  Fastening soles to vamps in one step to replace the complicated procedure of gluing, sole-attaching and pressing.

·  It can produce foam soles, high-transparent P.V.C., T.P.R. and PU soles so as to replace the cross ejector.

·  The ejecting quantity is controlled by the photo-cell digital system.Two kinds of machines are available-one with eight kinds of ejection capacity and the other with twelve kinds of ejection capacity.

·  It can join soles of sporting shoes or it can also eject whole plastic soles.

·  After the required quantity has been ejected, the hydraulic system will automatically move the disc to another position.



Product Specifications

Item

UNIT

EIGHT MOLDS

TWELVE MOLDS

Screw rod diameter

mm

72

72

Ejective capacity

cm 3/shot

680

680

Screw revolution

r.p.m.

60-110

60-110

Stroke of mold clamping

mm

50

50

Size of mold available

mm

170 X 360

170 X 360

Motor of oil-pressure pump

kw/pole

4P x 3HP/6P X 20HP

4P x 3HP/6P X 20HP

Oil-pressure motor for screw rod driving

kg/m

230

230

Electric heating capacity

kw

8 , 10.4 , 4.8

8 , 10.4 , 4.8

Acting oil capacity

L

280

280

Machine weight

ton

7.3

9.8

Machine volume

mm

4950 X 2220 X 2100

5800 X 2600 X 2200

Gross weight

ton

8.8

11.5

Packing dimention

mm

5350 X 2330 X 2470

6200 X 2710 X 2570
