ME-AP Series Flame Photometer
Application:
Used for analyzing & measuring the content & concentration of elements (K, Na, Li, Ca, Ba). Widely applied
to agriculture (soil, fertilizer, tobacoo), industry(cement,glass,ceramics,mineral or ore powder,fireproof material),
food (wine, water), laboratory, clinical experiments and pathology research (serum, urine, plasma), etc.
Features:
² Operates on propane, butane or liquefied petroleum gas.
² Standard accessories: air-compressor, PC software or micro-printer.
² LCD Display, touch panel with numeric keypad.
² Single point calibration & calibration curve can be saved.
² With 5 channels and be able to detect K, Na, Li, Ca, Ba 5 elements. With K, Na, Li, Ca, Ba five filters, which can detect three kinds of elements, show three kinds of element content simultaneous.
Specificatons:
Model |
ME-AP1500 |
ME-AP1401 |
ME-AP1402 |
ME-AP1301 |
ME-AP1302 |
ME-AP1200 |
|
Measure Range (ppm) |
K: 0-100 Na:0-100 Li: 0-100 Ca:0-1000 Ba:0-3000 |
K: 0-100 Na: 0-100 Li: 0-100 Ca: 0-1000 |
K: 0-100 Na: 0-100 Li: 0-100 Ba: 0-3000 |
K: 0-100Na: 0-100 Li: 0-100 |
K: 0-100 Na: 0-100 Ca: 0-1000 |
K: 0-100 Na: 0-100 |
|
Measure Limit (ppm) |
K: 0.01; Na: 0.01; Li: 0.025; Ca: 0.1; Ba: 10; |
K: 0.01; Na: 0.01; Li: 0.025; Ca: 0.1; |
K: 0.01 Na: 0.01 Li: 0.025 Ba: 10 |
K: 0.01Na: 0.01Li: 0.025
|
K: 0.01 Na: 0.01 Ca: 0.1
|
K: 0.01 Na: 0.01
|
Drift |
≤ 3% (after 30 minutes when the instrument stability) |
|||||
Sample Rate |
4 ~ 6ml/min |
|||||
Linearity |
Better than the best results of the intermediate value of 2% (single-point CAL) |
|||||
Response Time |
≤8s |
|||||
Time Stability |
Less than 15 seconds (when the sample was taken after the flame |
|||||
Calibration Methods |
Straight line, broken line, secondary fitting |
|||||
Size & Weight |
530*510*580mm & 27kg |
|||||
If you order, we will provide the professional printer or PC software for you freely ! | ||||||
