Help Center2 Layers Plastic Air Bubble Film Making Machine
Related Products
-
7-layer Air Bubble Aluminum Foil Compound MachineUS$ 69,000 - 110,000MOQ: 1 Set -
5-layer Air Bubble Aluminum Foil LaminatorUS$ 42,000 - 78,000MOQ: 1 Set
-
Plastic Air Bubble Wrap MachineUS$ 69,000 - 110,000MOQ: 1 Set
-
5-layer Aluminized Bubble Wrap MachineUS$ 52,000 - 90,000MOQ: 1 Set
-
Polyethylene Air Bubble Film Making MachineUS$ 27,000 - 48,000MOQ: 1 Set
Specifications
1. inner water cooling mould, good cooling effect; 2. fast producing speed; 3. good product quality.Air bubble film machine (model: MX-B150D)
Introduction
The air bubble film machine produces 2 layers air bubble film with new or recylced LDPE, LLDPE.
This final product is popular as a kind of packaging material. It enjoys such advantages as good shock absorption capability, impact resistance, heal sealing capability, corrosion resistance and good diaphaneity performance, etc.
This machine can prodcue two layers air bubble film with the max width 1500mm, shorter film can be also made by inserting a deckel in the die lip.
Other Features
Magnet tension control device Edge Wastage Mille
# For Magnet one, tension is good enough to spread the aluminum foil or other material well. The finish product looks quite ideal
# It is one equipment that cuts edge wastage into pieces, then the blower blows these pieces into hopper to mix with LDPE granule to make air bubble film again
Main technologic parameters.
Model |
MX-B100D |
MX-B150D |
MX-B160D |
MX-B250D |
Screw diameter mm |
Φ 65 |
Φ 75 |
Φ 75 |
Φ 110 |
Ways of changing net |
simple |
|||
Width mm |
1000 |
1500 |
1600 |
2500 |
Max output kg/hr |
75 |
105 |
105 |
180 |
Max effciency m/hr |
1100 |
1000 |
1000 |
1000 |
Total power kw |
70 |
92 |
95 |
130 |
Consumption power kw |
30~42 |
40~55 |
42~58 |
70~90 |
Layer |
2 |
2 |
2 |
2 |
Weight kg |
3800 |
4400 |
4800 |
6500 |
