Alarm System Keypad Work With Alarm Panel

Alarm system keypad work with alarm panel

Model: PH-101

Wireless control keypad

1- The wireless control keypad is specially designed for arm/disarm the alarm host with password authentication, which can be installed at the gates.

2- Wireless transmitting: 433MHZ/315MHZ for optional,

Transmitting distance: over 200 meters ( in the open area)

It’s adopt 2262 fixed encode chip, so the transmission encode data of arm/disarm can be programmed to modify. It’s suitable for all the alarm hosts with fixed code.

3-It adopts DIP switch encode mode, very easy to encode with the alarm host. EV1527 learning encode mode for option (the alarm host with learning code)

4- With 2 passwords.

Administration password: can modify the setting information, arm/disarm, program the alarm phone number, modifying the password of sub-password, etc

Sub-password.: Only for arm/disarm

5-With rechargeable standby battery, even power failure, it can keep working 6 months.

6-With LED backlight, it can operate even at night or in dark place.

7-With tamper switch, avoiding vandalism.

8-Automatically enter low-power consumption mode when no any operation.

9-Size: 117mm x 117mm x 21mm

10. Configuration: Wireless control keypad x 1

               12V/1A power adapter x 1

Include

One Keypad
One AC adapter
One English user manual

Specification of main unit:
Output power: DC12V
Input power: AC110V to 240V,50Hz or 60 Hz
Working hours of standby Battery(DC12V):
More than 6 months
Wireless frequency for above
accessories:433MHZ

Notes: the wireless keypad is installed at the gates, it can control the alarm host. When some visitors visit your house, he/she need to arm/disarm the alarm host with password prove. It's a very useful wireless keypad. Sure, the host can modify the sub-passwords, so that secure the house.
