SC-801 Wifi VoIP Router, Wifi ATA 802.11n 300M AP Router With VoIP and HNAT

SC-801 Wifi VoIP Router, Wifi ATA 802.11n 300M AP Router With VoIP and HNAT thumbnail-1
SC-801 Wifi VoIP Router, Wifi ATA 802.11n 300M AP Router With VoIP and HNAT thumbnail-2
SC-801 Wifi VoIP Router, Wifi ATA 802.11n 300M AP Router With VoIP and HNAT photo-1
SC-801 Wifi VoIP Router, Wifi ATA 802.11n 300M AP Router With VoIP and HNAT photo-2
US$ 1 - 99 MOQ: 100 Units
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
OEM
Model Number:
SC-801
Contact Supplier Request Quote Chat Now
Suncomm Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Taipei
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Brand Name OEM
Model Number SC-801
Product Description



SC-801WAU WifiVoIP Router

802.11n 300M AP Router with VoIP and HNAT

The Intelligent Communication Device for Next Generation Network



Specification

VoIP SoC

n  CPU Core: MIPS24KEc(400MHz)

Applications

n  Support NAT mode and Bridge mode

n  Support DDNS

n  MAC address cloning

n  SIP proxy redundancy

n  NAT Traversal by STUN

n  Built-in Wired speed NAT Router

n  DHCP Server and Client

n  IP conflict detection

n  VLAN

n  Flow Control

n  VPN Pass through (PPTP,L2TP and IPSec)

n  Port forwarding and DMZ host

n  Rate Limit per port

n  Broadcast Storm Control

n  Classification by physical port, IP port, 802.1p,DSCP and TCP/UDP port

n  Marking by 802.1p and DSCP

n  MAC filter per port

n  Packer filter for port, IP address, protocol and physical port

n  Firewall defend attack and UDP flooding

Management

n  Firmware Upgrade

n  Web Management Interface

n  IVR-driven Management Interface

n  Local and Remote Syslog (RFC3164)

n  Auto Provisioning

n  SNTP Time Synchronization

n  Multi User Level

n  SNMP v2

n  Telnet

n  TR069

n  System Log: local log and remote log

Call Features

n  3-way conference

n  Call hold

n  Call forwarding

n  Call Transfer

n  Call waiting

n  Caller ID and CWCID

n  DTMF Relay: In-band, Out-band and SIP INFO

n  QoS Layer 3

n  Call Log

n  CID/CWCID

n  Dial Plan

n  DTMF Mode: Inband, outband and SIP Info

Dimension

n  (L) 180 x (W) 110 x (H) 30 mm

Unit Weight

n  338 g ( without package)



Flash

n  8MBytes Flash

RAM

n  32MBytes DDR2

Power

Supply

n  AC/DC Adapter

²   AC Input: 100~240V, 50~60Hz

²   DC Output: 5V, 2A

I/O Interfaces

n  1 RJ-45 for WAN port (Ethernet 10/100 Base-T)

n  4 RJ-45 for LAN port (Ethernet 10/100 Base-T)

n  1 RJ-11 for FXS port

n  Two 5dB Antenna for IEEE802.11n 2T2R Wireless

Environmental

n  Operation Temperature: 0~45 Degree C

n  Storage Temperature: -25~ 85 Degree C

n  Relative Humidity: 10%~90% No Condensing

n  Shock: Up to 75cm (`30 inches)

Key Feature

n  Hardware NAT(HNAT) engine with 100Mbps NAT/NAPT speed

n  Wireless throughput is above 80Mbps in average

n  Support VoIP FXS port with SIP and T.38 FAX

Audio Codec

n  G.711 (A-Law, u-Law) with PAMS above 4.0

n  G.729 with PAMS above 3.6

n  Adaptive Jitter Buffer Management

n  Voice Activity Detection

n  Comfort Noise Generation

n  Echo Cancellation

n  T.30 FAX with G.711

n  Real time FAX over IP via T.38

Protocols

n  SIP V2 (RFC 3261, 3262, 3263, 3264)

n  Backward compatible with RFC2543

n  Session timer (RFC4028)

n  SDP (RFC2327)

n  RTP/RTCP (RFC823/903)

n  NAPTR for SIP URI lookup (RFC2915)

n  STUN (RFC2030)

n  ARP/RARP (RFC 826/903)

n  SNTP (RFC 2030)

n  DHCP/PPPoE

n  HTTP Server for Web Management

n  TFTP/HTTP for Auto Provisioning

n  Message Waiting Indicator (RFC3842)

n  DHCP Option Codes for SIP (RFC3361)

n  DNS/DNS SRV (RFC1706 and RFC 2782)

n  IEEE802.1Q VLAN/802.1p and IP DSCP

Wireless

n  802.11 b/g/n support

n  4 SSID

n  Static WEP(64/128bit)

n  Dynamic WEP(64/128bit)

n  AES(CCMP/TKIP)

n  MAC certification

n  WEP certification

n  WPA-PAK/WPA-PSK(2.0)

n  WPA/WPA2

n  AP Isolation and MBSSID AP Isolation

n  WMM

n  WDS

n  WPS

n  Station list

n  Radius certification and billing

n  MAC Filter(different from wired MAC Filter)
