Home > Electrical & Electronics > Passive Components > Other Passive Components > 0.35-1GHz Hybrid Couplers 200W
0.35-1GHz Hybrid Couplers 200W
Negotiable
MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
SETSAIL
Model Number:
YF-HC-3510-3dB-NF
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hybrid Coupler 90NegotiableMOQ: 50 Pieces -
Stripline Hybrid Coupler 698-2700MHz N-typeNegotiableMOQ: 10 Pieces
-
(698-2700MHz) N-type Wilkinson 3dB Hybrid CouplerUS$ 5 - 15MOQ: 10 Pieces
-
N-type Wilkinson 3dB RF Hybrid Coupler (698-2700MHz)US$ 5 - 15MOQ: 10 Pieces
-
N-type Wilkinson Hybrid Coupler 3dB (698-2700MHz)US$ 1.2 - 5MOQ: 10 Pieces
Place of Origin
Anhui, China
Brand Name
SETSAIL
Model Number
YF-HC-3510-3dB-NF
Specifications
0.35-1GHz Hybrid Couplers 200WaLow isolation hybrid coupler
Low Loss & VSWR Hybrid coupler
ZTE supplier hybrid coupler
A hybrid coupler is a passive device used in radio and telecommunications. It is a type of directional coupler where the input power is equally divided between two output ports. Since it is a special case of directional coupler, it is discussed in Power dividers and directional couplers.
Technical Specifications:2
0.35-1GHz Hybrid Coupler 200W
Product Name |
0.35-1GHz HybridCoupler 200W |
Model |
YF-HC-3510-3dB-NF |
Frequency(MHz) |
350-1000MHz |
Insertion Loss(dB) |
<=0.5 |
Isolation(dB) |
>=25 |
VSWR |
<=1.25:1 |
Power Capacity(W) |
200 |
Impedance(ohm) |
50 |
RF Connector |
N-female |
Operating Temperature(deg) |
-35~+70 |
Color |
Black-plated |
Relative Humidity |
5%-95% |
Weight(kg) |
0.420 |
