6/17 DIN-F Coupler 3dB
Negotiable
MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
SETSAIL
Model Number:
YFTX-RFHC-0825-3dB-200-DINF
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Anhui, China
Brand Name
SETSAIL
Model Number
YFTX-RFHC-0825-3dB-200-DINF
Specifications
1.Manufacturer of 3 dB hybrid coupler2.Din female connector
3.OEM Services
4. Two years services
A hybrid coupleris a passive device used in radio and telecommunications. It is a type of directional coupler where the input power is equally divided between two output ports. Since it is a special case of directional coupler, it is discussed in Power dividers and directional couplers.
6/17 DIN-F 3dB Hybrid Coupler
Product Name |
800-2500MHz 3dB Hybrid Couplers (DIN-female Connector) |
Model |
YFTX-RFHC-0825-3dB-200-DINF |
Frequency(MHz) |
800-2500698-2700MHz |
Insertion Loss(dB) |
<=0.55 |
Isolation(dB) |
>=23 |
Coupling(dB) |
3 |
VSWR |
<=1.25:1 |
PIM3 |
<=-140dBc@2×43dBm |
Waterproof |
IP65 |
Power Capacity(W) |
200 |
Impedance(ohm) |
50 |
RF Connector |
DIN-female |
Operating Temperature(deg) |
-35~+70 |
Application |
Indoor or Outdoor |
Material |
Aluminum |
Color |
Black-plated |
Relative Humidity |
5%-95% |
