NE Semi-electric Mini Stacker
Negotiable
MOQ: 2 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
SINOLIFT
Model Number:
NE
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shanghai, China
Brand Name
SINOLIFT
Model Number
NE
After-sales Service Provided
Overseas service center available
Specifications
Ideal for use in narrow aisles and confined spaces.Electric Stacker NE series
A range of highly manoeuvrable, lightweight lifts, designed to take the strain out of any lifting job from ground level to over shoulder height.
Ideal for use in narrow aisles and confined spaces. Perfect for all applications from pharmaceutical to catering, from packing line to food processing, from warehouse to office, kitchens, laboratories, retail outlets, etc...
Quick lift pump provides high efficiency.
No-marking castor as standard.
Conforms to EN1757.
| Model(Adjustable Fork) | NE4012PA | NE4012PB | NE4012F | |
| Type | Platform | Platform | Adjustable Fork | |
| Capacity | (kg) | 400 | 400 | 400 |
| Max.Fork Height | H2 (mm) | 1210 | 1270 | — |
| Min.Fork Height | H1 (mm) | 90 | 150 | 90 |
| Platform Length | L1 (mm) | 670 | 670 | — |
| Platform Width | W1 (mm) | 590 | 590 | — |
| Min. Fork Height | h1 (mm) | — | — | 90 |
| Max. Fork Height | h2 (mm) | — | — | 1210 |
| Fork Length | L2 (mm) | — | — | 700 |
| Single Fork Width | (mm) | — | — | 90 |
| Fork Width | W2 (mm) | — | — | 190-572 |
| Dia of Front Wheel | D (mm) | Ø75 | Ø75 | Ø75 |
| Dia Steering Wheel | d (mm) | Ø125 | Ø125 | Ø125 |
| Power Pack Motor | (KW) | 0.8 | 0.8 | 0.8 |
| Battery | (V/Ah) | 12/70 | 12/70 | 12/70 |
| Overall Height | H (mm) | 1610 | 1635 | 1610 |
| Overall Width | W (mm) | 620 | 620 | 620 |
| Overall Length | L (mm) | 1190 | 1190 | 1270 |
| Net Weight | (kg) | 116 | 118 | 117 |
