FS-50T Advanced ARC Fusion Splicer

Specifications

Overview

FS-50T Series  advanced ARC fusion splicer can quickly and precisionly splice fiber in 8 seconds.

With the high-speed image processing technology and special precision-positioning technology, the whole splicing process would be clearly displayed on 5.6" TFT LCD touch screen

FS-50T Series advanced ARC fusion splicer is widely used for SM and MM Quartz Fiber with diameter 80-150μm, coating layer diameter 0.1-1.0mm and bare fiber length 16mm more or less.

To meet worldwide customers using requirement, FS-50T Series Splicing Machine support multi-language including Chinese, Japanese, Germany, Spanish, Russian, Korea, Portuguese, French, Italian, Turkish, English etc.

Features

• Advanced ARC fusion splicer
• 8 seconds splicing time,
• 28 seconds Heat-Shrinking
• Rugged,lightweight and portable
• 2.8kg in weight
• 5.6 "TFT color LCD monitor with anti-reflective coating
• Advanced core to core fiber profile alignment system (PAS)
• ARC Calibration FREE system
• Included ARC Calibration sub-menu supports manual ARC Calibration
• X/Y axes was displayed simultaneously or separately
• Up to 300 times magnification
• Real-time display of battery capacity
• Built-in high capacity battery, support 220 cycles (splicing /tube heating)
• Up to 4000 times long Electrode Lifetime
• High protection wind-cover
• Max. wind velocity of 15m/s
• Two Splicing modes: auto, manual
• Built-in super high-brightness LED supply convenience for night work
• Auto  splicing loss calculation
• 4000 results Storage
• 2.0 USB data interface &VGA
• Carrying Case can also act as working table to splice the fiber
• One button operation to finish results download or software update
• Close shield to splice automatically; close heater lid to heat automatically
• One-year warranty

 Specification

Standard Accessories

1)   Main unit

2)   High precision cleaver

3)   Power adapter

4)   Battery pack

5)   Blow blush

6)   Cooling tray

7)   Monitor coating

8)   USB flash disk

9)   Fiber stripper

10) Battery charger cable

11)  Spare electrodes

12)  V-groove cleaning

13)  CD

14)  Alcohol dispenser

15)  Monitor cover

16)  Carrying case

17)  Manual
