1000KW Single Nozzle Pelton Water Turbine
- 20 Set / Sets per Month
- Chongqing
- T/T
- Sealing tile at the steam end (hydrogen side) QFSN-1000-2-27 for Bangladesh Power Plant
- Photovoltaic module production line equipment introduction
- Solar panel production line program introduction
- Pv panel packaging production equipment price
- 500MW automatic photovoltaic module production line
- 100MW solar photovoltaic module production line, full set of panel production equipment
Product Details
Place of Origin: | Chongqing, China | Brand Name: | Hi-Sea | Model Number: | Pelton Turbine |
Electricity Generator Type: | Hydro Power | Output Voltage (V): | 6300 |
Product Description
Specifications
pelton turbine:1.Power:800~8000kw
2.Water Head:150~600m
3.Runner Diameter:0.9m 1.25m
4.Frequency:50Hz 60Hz
pelton turbine:
1000KW Single Nozzle Pelton Water Turbine
Pelton turbine (also called impulse turbine or action turbine) is the best choice for developing high water head with little flow water power resource. It has good characteristics like less investment, high efficiency, small size and compact structure. Pelton turbine units made by Hi-Sea Marine are suitable for 80~1000m water head with runner diameter 0.6~1.8m and capacity 100~18000kw. Both vertical and horizontal types can be provided, with single nozzle, twin or multi nozzles.
This is technical parameters of 1000kw pelton turbine with single nozzle and runner diameter from 0.9-1.25m.
Runner Diameter(m) | Jet Diameter(m) | Design Head(m) | Design Flow(m3/s) | Output(KW) | Speed(r/min) | Power(KW) | Voltage(V) | Efficiency(%) | Model |
0.9 | 0.11 | 260 | 0.52 | 1112 | 750 | 1000 | 6300 | 94 | Φ400 Butterfly Valve |
0.9 | 0.07 | 320 | 0.49 | 112 | 750 | 1000 | 6300 | 94 | Φ400 Butterfly Valve |
1.1 | 0.125 | 200 | 0.67 | 1115 | 500 | 1000 | 6300 | 94 | Φ500 Gate Valve |
1.1 | 0.11 | 245 | 0.55 | 1115 | 600 | 1000 | 6300 | 94 | Φ400 Gate Valve |
1.1 | 0.09 | 295 | 0.46 | 1115 | 600 | 1000 | 6300 | 94 | Φ400 Gate Valve |
1.25 | 0.09 | 290 | 0.47 | 1130 | 500 | 1000 | 6300 | 94 | Φ400 Butterfly Valve |
1.25 | 0.11 | 255 | 0.54 | 1115 | 500 | 1000 | 6300 | 94 | Φ400 Butterfly Valve |
1.25 | 0.125 | 180 | 0.70 | 1088 | 428 | 1000 | 6300 | 94 | Φ500 Butterfly Valve |
1.25 | 0.14 | 185 | 0.73 | 1087 | 428 | 1000 | 6300 | 95 | Φ500 Butterfly Valve |
1000KW Single Nozzle Pelton Water Turbine
