Help CenterSingle Nozzle Pelton Turbine
Related Products
Specifications
pelton turbine:1.Power:630~5000kw
2.Water Head:150~800m
3.Runner Diameter:0.9~1.25m
4.Frequency:50Hz and 60Hz
pelton turbine:
Single Nozzle Pelton Turbine
Pelton turbine(also called impulse turbine or action turbine) is the best model for developing high water head with little flow water power resources. It has good characteristics like less investment, high efficiency, small size and compact structure. Pelton turbine units made by Hi-Sea Marine are suitable for 80~1000m water head with runner diameter 0.6~1.8m and capacity 100~18000kw. Both vertical and horizontal types can be provided with single nozzle, twin or multi- nozzles.
This is technical parameters of 800kw single nozzle pelton turbine with runner diameter 0.9m
| Jet Diameter(m) | Design Head(m) | Design Flow(m3/s) | Output(KW) | Speed(r/min) | Power(KW) | Voltage(V) | Efficiency(%) | Valve Model |
| 0.11 | 230 | 0.45 | 880 | 600 | 800 | 6300 | 94 | Φ400Butterfly Valve |
| 0.07 | 280 | 0.40 | 887 | 750 | 800 | 6300 | 94 | Φ400Butterfly Valve |
This is technical parameters of 2500kw single nozzle pelton turbine with runner diameter 0.9m, 1.1m, 1.25m
| Runner Diameter(m) | Jet Diameter(m) | Design Head(m) | Design Flow(m3/s) | Output(KW) | Speed(r/min) | Power(KW) | Voltage(V) | Efficiency(%) | Valve Model |
| 0.9 | 0.11 | 480 | 0.71 | 2780 | 1000 | 2500 | 6300 | 95 | Φ400Butterfly Valve |
| 0.9 | 0.07 | 600 | 0.65 | 2780 | 1000 | 2500 | 6300 | 95 | Φ400Butterfly Valve |
| 1.1 | 0.125 | 375 | 0.90 | 2780 | 750 | 2500 | 6300 | 95 | Φ500Gate Valve |
| 1.1 | 0.11 | 425 | 0.75 | 2632 | 750 | 2500 | 6300 | 95 | Φ400Gate Valve |
| 1.1 | 0.09 | 520 | 0.62 | 2662 | 750 | 2500 | 6300 | 95 | Φ400Gate Valve |
| 1.25 | 0.09 | 540 | 0.59 | 2719 | 750 | 2500 | 6300 | 95 | Φ400Butterfly Valve |
| 1.25 | 0.11 | 465 | 0.73 | 2780 | 750 | 2500 | 6300 | 95 | Φ400Butterfly Valve |
| 1.25 | 0.125 | 340 | 0.97 | 2755 | 600 | 2500 | 6300 | 95 | Φ500Butterfly Valve |
| 1.25 | 0.14 | 339 | 1.00 | 2780 | 600 | 2500 | 6300 | 94 | Φ500Butterfly Valve |
800kw single nozzle pelton turbine
2500kw single nozzle pelton turbine
