1.5 Ton Diesel Forklift Truck

1.5 Ton Diesel Forklift Truck thumbnail-1
1.5 Ton Diesel Forklift Truck photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Chongqing, China
Brand Name:
HI-SEA MARINE
Contact Supplier Request Quote Chat Now
Chongqing Hi-Sea Marine Equipment Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Chongqing, China
Brand Name HI-SEA MARINE
Model Number FD15
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 1.5 Ton
Max. Lifting Height 3860mm
Min. Lifting Height 105 mm
Fork Length 1070 mm
Fork Width 100 mm
Overall Dimensions 1070x100x35 mm
Certification CE,ISO9001 etc
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.1.5T Forklift Truck
2.Wide visual field
3.Beautiful display meter
4.Spacious space
5.Excellent effect of distribute heat

 1.5 Ton Forklift Truck



 Features :

1.  Good lighting:

There are five transparent plastic covers on the top,so it has good lighting effect and waterproof function.

2.  Wide visual field:

Widen msat design, open visual field , increase the work efficiency and safety operarion.

3.  Beautiful display meter:

LCD display meter,feedback the working condition in time,integrated electric system,testing and maintenance easily.

4. Spacious space:

Operating space increase by 10 percent ,make the driver's operating more comfortable.

5. Excellent effect of distribute heat :

Air vent on the back of the forklift increase by 10 percent, which is benefit water tank to istribute heat



Standard specifications:



Model

Diesel 1.5T




FD15




FD15Y-X2

FD15Y-W2

FD15Y-Ym1

Power

Engine

Model



Xinchai

Isuzu C240

Yanmar


NC485

PKJ-30

4TNE92


Rated Power

kw/r.p.m

30/2600

34/2500

33/2450


Rated Torque

Nm/r.p.m

131/1800

138/1800

150/1600


Bore×Stroke

mm

85X100

86x102

92×110


Cylinder Amount

4

4

4


Displacement

L

2.27

2.4

2.659


Gears



1/1 Power Shift

1/1 Power Shift

1/1 Power Shift


Working Pressure

Mpa

14.5

14.5

14.5


Battery

Voltage/Capacity

V/Ah

12/90

12/90

12/90

Features

Rated Load



kg

1500

1500

1500


Load Center



mm

500

500

500


Lifting Height



mm

3000

3000

3000


Free Lifting Height

mm

115

115

115


Fork Size

Long×Wide×Thick

mm

1070x100x35

1070x100x35

1070x100x35


Mast Tilt Angle

Front/Rear

.

6/12

6/12

6/12


Minimum Turning Radius

mm

2060

2060

2060


Minimum Stacking Right

mm

3680

3680

3680


Angle Channel Width




Minimum Right

mm

1865

1865

1865


Angle Channel Width




Minimum Ground Clearance

mm

105

105

105


Front Overhang

mm

400

400

400



More specification,Please contact us.



Standard facility:



Wide view mast.  Standard forks.  Standard seat. Charging indicator. Load backrest.  Reversing lamp. Reversing buzzer. Reverse mirror.  Lighting switch. Light guard. Horn. Two pieces of multiway valve. Engine misses device. Rear combined lamps. Transparency mask of overhead guard. Rib tire. Hour meter. Neutral indicator. Air filter clog warning. Cable parking brake. Lifting and tilting level. Hoist cylinder oil relief valve. Clevis pin. Light. Tilt steering wheel. Tilt oil channel self-locking valve. Hydraulic power steering. Top intake duct. Hand lever. Water temperature indicator. Tool box. Foot board rubber pad. Whirlwind type air cleaner. Combination instrument. Hydraulic oil circuit element. Hydraulic oil scale. Oil-pressure warning. Lock switch. Brake. Direction indicator lamp



Optional attachment:



Windshield. Multiway valve. Top grade seat. High air exhausting device. Driving cab. Warm air blower. Air cleaner and silence. Quencher. Solid tyre. Double air filter. Warning light. Small fan. Color tyre. (white, green )



Attachments:
Side shifter. Fork positioner. Hinged fork. Carpet boom. Crane jib. Fork.. Fork extension. Lifting arm. Paper roll clamp. Bale clamp



Pictures:

1.5 Ton Diesel Forklift Truck



1.5 Ton Diesel Forklift Truck

For  more informaiton of 1.5 Ton Forklift Truck or others, Please get contact with us.
