YT series Six-Color Flexographic Printing Machine

Specifications

It is a kind of ideal printing equipment for producing paper packing bags for food, supermarket handbags, vest bags .

Features:
1) Easy operation, flexible starting, accurate color register
2) The meter counter can set printing quantity according to the requirements, stop the machine automatically at the quantity or when the material is cut off
3) Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting
4) The printing ink is spread by the anilox cylinder with even ink color
5) Due to the reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops
6) 360 degrees continuous and adjustable longitudinal register device
7) The frequency control of motor speed adapts to different printing speeds
8) There are jogging / stopping buttons on the plate roller base and material rolling rack so as to make it easy to operate the machine when the plate is installed
9) Application: introducing sensitization resin as flexible printing plate, it is suitable for printing such packing materials as polyethylene, polypropylene bag, and cellophane and roll paper. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbags, vest bags and clothes bags.



Main Technical Variables:





Model of Machine	YT-6600	YT-6800	YT-61000
Max.Width of Printing Material	600mm	800mm	1000mm
Max.Printing With	560mm	760mm	960mm
Length Range of Printed Product	190-940mm	190-940mm	190-940mm
Max.Diameter of Roll Material	φ450mm	φ450mm	φ450mm
Printing Speed	50m/min	50m/min	50m/min
Thickness of plate(Including Two-sides Glue Paper)	2.38mm	2.38mm	2.38mm
Overall Dimensions	4200×1600×2400mm	4200×1600×2800mm	4200×2000×2800mm
