DSA1030A spectrum analyzer frequency domain 9 kHz~3 GHz RBW 10 Hz to 1 MHz
DSA1030A spectrum analyzer frequency domain 9 kHz~3 GHz RBW 10 Hz to 1 MHz
product feature:
DSA1030A for small volume, light weight and excellent portable spectrum analyzer,
its good performance, can meet the needs of most of the radio frequency related
applications. The realization of the digital intermediate frequency to ensure its
excellent performance and stable performance. The parameters of the original
application of widescreen, show originality, icon design and humanized design in
various places make spectrum measurement has never been easy and quick.
1.1 The digital intermediate frequency technology
1.2 9 kHz to 3 GHz frequency range
1.3 According to the average noise level (DANL) - 148 dBm
1.4 Phase noise is typical values - 88 dBc/Hz (offset 10 KHZ)
1.5 Whole range accuracy < 1.0 dB
1.6 Minimum resolution bandwidth (RBW) 10 Hz
1.7 The EMI filter of the standard and function of peak detector
1.8 The standard preamplifier
1.9 3 GHz tracking source (applicable to DSA1030A - TG)
2.0 Built-in lithium battery, continuous work 3 hours (optional)
2.1 Measurement functions and a variety of automatic setting function
2.2 Rich interface: LAN, USB Host, USB Device, VGA GPIB (optional)
2.3 Compact design, the weight is only 6.2 kg (without battery)
2.4 8.5 -inch WVGA Gao Qingbing (800 x480
Edited By Evan
