SA5061 Digital Multimeter

SA5061 Digital Multimeter thumbnail-1
SA5061 Digital Multimeter photo-1
US$ 1,150 - 1,300 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Model Number:
SA5061
Measuring Current Range:
10mA/100mA/1A/3A
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Model Number SA5061
Measuring Current Range 10mA/100mA/1A/3A
Measuring Voltage Range 100mV/1V/10V/100V/1000V
Measuring Resistance Range 100Ω/1KΩ/10KΩ/100KΩ/1MΩ/10MΩ/100MΩ
Operating Temperature -270 ~ 1372℃

     SA5061 Digital Multimeter



                                                      SA5061 Digital Multimeter





Features:
  • VFD display with high-brightness
  • True 6½ digits
  • Reading rates up to 1000 readings per second
  • True RMS measurement of AC voltage and current
  • Built-in math operations
  • Full measuring functions to meet user’s test need
  • Standard interface RS-232 and USB Device, optional interface of GPIB

Specifications:

Basic Function

Range

Best Accuracy

DC Voltage

100mV/1V/10V/100V/1000V

± (0.0035% + 0.0005%)

AC Voltage

100mV/1V/10V/100V/750V

± (0.06% + 0.03%)

DC Current

10mA/100mA/1A/3A

± (0.05%+0.02%)

AC Current

1A/3A

± (0.30%+0.04%)

Resistance

100Ω/1KΩ/10KΩ/100KΩ/

± (0.01%+0.002%)

1MΩ/10MΩ/100MΩ

Frequency

3Hz/300KHz

± 0.01%

Temperature

-270 ~ 1372℃

Features

Reading Rate

1000 reading/s

Auto Range

√

Diode

√

Continuity

√

Null

√

Trigger

√

Save/Read

√

Math

MAX.MIN, Average, dB, dBm, Limit Test

General Characteristics

Interface

USB, RS-232, GBIP (optional)

Power

110 V/220 V±10%, 50 Hz/60 Hz, 15 VA

Dimension & Weight

260/106/375 mm, Approx. 3.0 kg







  Accessories




Power Cord

1

Test Lead Kit

1

Aligator Clip

1

Temperature Probe

1

CD(User's Guide)

1







Edited by Cathy
