SA5041 Digital Multimeter

SA5041 Digital Multimeter thumbnail-1
SA5041 Digital Multimeter photo-1
US$ 168 - 200 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Model Number:
SA5041
Measuring Current Range:
200uA/2000uA/20mA/200mA/10A
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Model Number SA5041
Measuring Current Range 200uA/2000uA/20mA/200mA/10A
Measuring Voltage Range 200mV/2V/20V/200V/1000V
Measuring Resistance Range 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ
Measuring Capacitance Range 20nF/200nF/2uF/20uF/200uF/2mF/20mF
Operating Temperature -200 ~ 1000℃

     SA5041 Digital Multimeter



                                                      SA5041 Digital Multimeter





Features:
  • Economic and full functions
  • True 4½ digits with 19999 count
  • Measures DCV, ACV, DCA, ACA, resistance, capacitance, frequency and temperature
  • Tests diode and continuity
  • Save and reading function
  • Built-in math operations
  • Standard interface of USB Device

Specifications:



Range

Best Accuracy

Basic Functions

DC Voltage

200mV/2V/20V/200V/1000V

± (0.05% + 1)

AC Voltage

200mV/2V/20V/200V/750V

± (0.8% + 80)

DC Current

200uA/2000uA/20mA/200mA/10A

± (0.35%+10)

AC Current

200uA/2000uA/20mA/200mA/10A

± (0.8%+80)

Resistance

200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ

± (0.1%+5)

Capacitance

20nF/200nF/2uF/20uF/200uF/2mF/20mF

± (3.5%+20)

Frequency

20Hz/200Hz/2000Hz/20KHz/200KHz/2000KHz

± (1.0%+20)

/2MHz/20MHz/200MHz

Temperature

-200 ~ 1000℃

± (1%+30)

Other Functions

Display Count

19999

Auto Range

√

Diode

√

Continuity

√

Null

√

Trigger

√

Save/Read

√

Math

dB,dBm

General Characteristics

Interface

USB

Power

110 V/220 V±10%, 50 Hz/60 Hz, 15 VA

Dimension&Weight

260/106/375 mm, Approx. 1.5 kg





Edited by Cathy
