TES-1601 Auto Ranging Insulation Tester
US$ 373 - 399
/ Piece
1 Piece(Min. Order)
- ShenZhen
- T/T Money Gram Credit Card PayPal
You May Like
-
TES PROVA-5601 Non-Contact Clamp-on Ground Resistance Tester Meter 23mm Jaw 30A
-
Mastech MS6530B Thermometer Non Contact Infrared Thermometers
-
MASTECH MS5215 High Voltage Digital Insulation Tester
-
Megger High Precision Digital Insulation Resistance Meter Tester Multimeter 10G 2500V MASTECH MS5205
-
MASTECH MS5202 Digital Analogue Insulation Tester
-
Digital Megger the MS5203 50V/100V/250V/500V/1000V Digital Insulation Resistance Tester
Product Details
| Place of Origin | Guangdong, China | Brand Name | TES | |
| Model Number | TES-1601 | Display Type | Digital Only | |
| Dimensions | 190mm(L)x140mm(W)x77mm(H |
Product Description
Specifications
TES-1601 Auto Ranging Insulation Tester
TES-1601 Auto Ranging Insulation Tester
*2000MW/1000V, 200MW /500V, 200MW/250V
*Power lock for 3 minutes (Auto power off)
*Auto-Zero adjustment
*Data-Hold-Function
Specification:
AC Voltage:
Range | 600V |
Resolution | 1V |
Accuracy | 1.5% rdg + 3 dgts |
Input Impedance | 4.5MΩ |
Overload Protection | 750Vrms |
OHMS:
| Range | 400Ω |
| Resolution | 0.1W |
| Accuracy | 1% rdg + 5 dgts |
| Max open circuit voltage | 12.8V |
| Overload protection | 220Vrms |
MEG OHMS:
| Range | 4000MΩ/250V, 4000MΩ/500V, 4000MΩ/1000V |
| Resolution | 1K W |
| Accuracy | 3% rdg + 3 dgts |
| Terminal Voltage | 250V ~ 1000V ±2% ~ -0% |
| Output short circuit current | 0.4mA/0.9mA/1.7mA max |
| Operating/Storage Condition | 0°C to 40 °C< 80% R.H. -10°C to 60°C< 70% R. H. |
Continuity Beeper:
| Resolution | 0.1 W |
| Operation resistance | < 40Ω |
| Max open circuit voltage | 12.8V |
| Overload protection | 220Vrms |
General Specification:
| Power Source | 8pcs "AA" 1.5V batteries |
| Sampling Rate | 2.5 times/sec, Auto-Zero adjustment |
| Size | 190mm(L)x140mm(W)x77mm(H) |
| Weight | 900g |
| Accessories | Carrying Case, Test Lead, Battery & Instruction Manual |
