DC Wheatstone Bridge DY-B23A
US$ 350 - 380
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DUOYI
Model Number:
DY-B23A
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LCR Meter DY4070G, DY6243G, DY6013GUS$ 100 - 130MOQ: 1 Piece -
DY3165/DY3166 Analog Insulation Resistance TesterUS$ 100 - 150MOQ: 1 Piece
-
DY30-3 Digital Telecom Insulation TesterUS$ 160 - 200MOQ: 1 Piece
-
DY30-1/DY30-2 Digital Insulation Resistance TesterUS$ 150 - 200MOQ: 1 Piece
-
DY5104A, DY5105A Digital Insulation Resistance TesterUS$ 220 - 250MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
DUOYI
Model Number
DY-B23A
Display Type
Digital Only
Accuracy Class
1
Operating Temperature
0~60
Dimensions
320*280*170 mm
Specifications
DC Wheatstone Bridge DY-B23A
DC Wheatstone Bridge DY-B23A
Features
- Base on Wheatstone bridge circuit ranged from 0Ω - 11.110MΩ with resolution 1mΩ
- Built-in null-indicator and internal power supply, testing anywhere
- Solid and heavy duty box
DC WHEATSTONE BRIDGE DY-B23A
| Multiplying Power | Effective Span | RESOLUTION | ACCURACY |
|---|---|---|---|
| x10-3 | 0 ~ 11.110Ω | 1mΩ | 0.05 |
| x10-2 | 0 ~ 111.10Ω | 10mΩ | 0.05 |
| x10-1 | 0 ~ 1.1110kΩ | 100mΩ | 0.05 |
| x1 | 0 ~ 11.110kΩ | 1Ω | 0.05 |
| x10 | 0 ~ 111.10kΩ | 10Ω | 0.05 |
| x102 | 0 ~ 1.1110MΩ | 100Ω | 0.1 |
| x103 | 0 ~ 5.000MΩ | 1000Ω | 0.1 |
| 5 ~ 11.110Ω | 1000Ω | 0.1 |
- total range:0Ω - 11.110MΩ
- power supply: DC4.5V (AA1.5V * 3)
- null indicator power DC9V (6F22 * 1)
- dimension 320*280*170 mm
- weight: 6kg
