Resistance Decade Box DY-R9xE
Specifications
Resistance Decade Box DY-R9xE
Resistance Decade Box DY-R9xE
Features
- Five to seven dials provide precise and range rich resistances
- Light pressure switches to keep low contact resistance
- Alloy wires employed
Resistance Decade Box DY-R92E/R94E/R95E/R96E/R97E/R98E/R99E
| model | dials | max value (Ω) | min. step (Ω) | accuracy | dimension | weight | ||||||||
| x106 | x105 | x104 | x103 | x102 | x10 | x1 | x10-1 | x10-2 | L*W*H(mm) | (kg) | ||||
| R92E | 5 | 1111.10 | 0.01 | - | - | - | - | 0.1 | 0.1 | 0.5 | 2 | 5 | 242*95*94 | 1.0 |
| R94E | 5 | 111110 | 1 | - | - | 0.1 | 0.1 | 0.1 | 0.1 | 0.5 | - | - | 242*95*94 | 1.1 |
| R95E | 6 | 11111.10 | 0.01 | - | - | - | 0.1 | 0.1 | 0.1 | 0.5 | 2 | 5 | 284*95*94 | 1.15 |
| R96E | 6 | 111111.0 | 0.1 | - | - | 0.1 | 0.1 | 0.1 | 0.1 | 0.5 | 2 | - | 284*95*94 | 1.25 |
| R97E | 6 | 1111110 | 1 | - | 0.2 | 0.1 | 0.1 | 0.1 | 0.1 | 0.5 | - | - | 284*95*94 | 1.25 |
| R98E | 7 | 111111.10 | 0.01 | - | - | 0.1 | 0.1 | 0.1 | 0.1 | 0.5 | 2 | 5 | 327*95*94 | 1.35 |
| R99E | 7 | 1111111.0 | 0.1 | 0.2 | 0.2 | 0.1 | 0.1 | 0.1 | 0.1 | 0.5 | 2 | - | 327*95*94 | 1.35 |
- reference power: 0.5W
- normal power: 0.1
- max. threshold power 0.2
