Help CenterResistance Tester ZC29B-2
US$ 1 - 200
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
GRAIGAR
Model Number:
ZC29B-2
Measuring Range:
0~1Ω, 0~10Ω, 0~100Ω
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
GRAIGAR
Model Number
ZC29B-2
Measuring Range
0~1Ω, 0~10Ω, 0~100Ω
Operating Temperature
-20 degrees to +40 degrees
Dimensions
172*116*135mm
Specifications
Resistance Tester ZC29B-2
Resistance Tester ZC29B-2
Ground Resistance Tester is suitable for measuring the resistance value of the various power systems, electrical equipment, lightning rod grounding devices. You can also measure low resistance the conductor values and soil resistivity.
ZC29B-1 measurement Division value: 0.1 to 1000 ohm
ZC29B-2 to measure the value of indexing: 0.01 to 100 ohms
Operating temperature: -20 degrees to +40 degrees
Relative humidity: ≤ 80%
Accuracy: 3
Shake to speed: 150 rpm
Product Configuration: 2 auxiliary probe
Wire 5 m 1
20 m 1
40 m 1
Annex bags: a
Leather box packing
| The main technical indicators: | |||
| Specification | Measuring range | Smallest sub-grid | The grounding resistor value of the auxiliary probe |
| ZC29B-1 type | 0 ~ 10Ω | 0.1Ω | ≤ 1000Ω |
| 0 ~ 100Ω | 1Ω | ≤ 2000Ω | |
| 0 ~ 1000Ω | 10Ω | ≤ 5000Ω | |
| ZC29B-2 type | 0 ~ 1Ω | 0.01Ω | ≤ 500Ω |
| 0 ~ 10Ω | 0.1Ω | ≤ 1000Ω | |
| 0 ~ 100Ω | 1Ω | ≤ 2000Ω | |
| The level of accuracy | 3.0 | ||
| Working conditions | Temperature -20 ~ +40 , relative humidity ≤ 80% | ||
| The cranks Rated speed | 150r/min | ||
| Dimensions | 172mm × 116mm × 135mm | ||
| Weight | About 3.5kg | ||
