DY5101A, DY5102A Digital Insulation 3 Phase Tester
US$ 200 - 250
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DUOYI
Model Number:
DY5101A,DY5102A
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DY5106 Digital 5000V Insulation Resistance TesterUS$ 250 - 300MOQ: 1 Piece -
DY5103A Digital 5000V Insulation 3 Phase TesterUS$ 270 - 300MOQ: 1 Piece
-
DY4100 Digital Ground Resistance TesterUS$ 180 - 200MOQ: 1 Piece
-
DY4200 Digital Ground Resistance TesterUS$ 260 - 300MOQ: 1 Piece
-
DY4300 4-Terminal Ground Resistance and Soil Resistivity TesterUS$ 350 - 400MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
DUOYI
Model Number
DY5101A,DY5102A
Specifications
DY5101A, DY5102A Digital Insulation 3 Phase Tester
DY5101A, DY5102A Digital Insulation 3 Phase Tester
Features
- Three test voltages, measure insulation resistance to 20GΩ
- Measure insulation resistance to 200GΩ with 0.01mΩ resolution
- AC voltage measurement to 600V
- Check phase sequence and phase status
- Data hold, auto range, auto power off, LCD background light
- Complete with test leads, phase wire, heavy duty carry case and six 1.5V AA batteries
Specifications
Insulation 3 Phase Tester
| MODEL | DY5101A | DY5102A |
|---|---|---|
| Testing Voltage | 250/500/1000V | 500/1000/2500V |
| Insulation Resistance | 0.1~20GΩ ±(3%+5) | 0.1~20GΩ ±(3%+5) |
| Phase Rotation Check | yes | yes |
| AC V | 700V ±(2%+5) | 700V ±(2%+5) |
| Resolution | 0.01MΩ | 0.01MΩ |
| Auto Range | yes | yes |
| Function Symbol Display | yes | yes |
| Data Hold | yes | yes |
| Low Battery Warning | yes | yes |
| Max. Displays | 1999 | 1999 |
| LCD Backlight | yes | yes |
General Characteristics
| Power | AA1.5V*8 | |
| Product Size | 190*155*75 mm | |
| Product Net Weight | 900g | |
| Standard Accessories | ||
| Standard individual packing | Carry case | |
| Standard Quantity per Carton | 6 pcs. | |
| Measurement of Standard Carton | 645*360*276mm (0.064 CBM) | |
| Gross weight of Standard Carton | 14kgs | |
Features
- Three test voltages, measure insulation resistance to 20GΩ
- Measure insulation resistance to 200GΩ with 0.01mΩ resolution
- AC voltage measurement to 600V
- Check phase sequence and phase status
- Data hold, auto range, auto power off, LCD background light
- Complete with test leads, phase wire, heavy duty carry case and six 1.5V AA batteries
Specifications
Insulation 3 Phase Tester
| MODEL | DY5101A | DY5102A |
|---|---|---|
| Testing Voltage | 250/500/1000V | 500/1000/2500V |
| Insulation Resistance | 0.1~20GΩ ±(3%+5) | 0.1~20GΩ ±(3%+5) |
| Phase Rotation Check | yes | yes |
| AC V | 700V ±(2%+5) | 700V ±(2%+5) |
| Resolution | 0.01MΩ | 0.01MΩ |
| Auto Range | yes | yes |
| Function Symbol Display | yes | yes |
| Data Hold | yes | yes |
| Low Battery Warning | yes | yes |
| Max. Displays | 1999 | 1999 |
| LCD Backlight | yes | yes |
General Characteristics
| Power | AA1.5V*8 | |
| Product Size | 190*155*75 mm | |
| Product Net Weight | 900g | |
| Standard Accessories | ||
| Standard individual packing | Carry case | |
| Standard Quantity per Carton | 6 pcs. | |
| Measurement of Standard Carton | 645*360*276mm (0.064 CBM) | |
| Gross weight of Standard Carton | 14kgs | |
