Specifications
Free shipping YH351 With PC RS-232 Interface Three Phase Digital Power Clamp Meter Multimeter
Three-phase intelligent power clamp meter YH351
FEATURES
1, Power measurement of 3-phase 3-wire, 3-phase 4-wire, single-phase mode
2, V, A, W, VA, VAR, KWh, PF, Hz measurement
3, Double display two parameters on eash menu and store 28 groups of measurement parameter
4, Measure total power value and five power parameters of each phase in 3-phase measurement mode respectively
5, Autorange and TRMS display
6, With PC RS232 interface and windows graphics software
7, Display measurement time and select tested signal be power supply for the clamp at one time, the instrument can measurement for long time
8, Large LCD display, multifunctional button control
SPECIFICATIONS
Max Conductor Size |
50mm |
AC current(A) |
40/100/400/1000A±2% |
AC voltage(V) |
100/300/600V±1.2% |
Active power(kW) |
4/10/40/100/600kW±3.0% |
Apparent power(kVA) |
4/10/40/100/600kVA±3.0% |
Power factor(PF) |
0.3cap to 0.3ind±0.02% |
Reactive power(KVAR) |
4/10/40/100/600kVAR±4.0% |
Active energy(kWh) |
10/100/1000/10000kWh±3.0% |
Frequency(Hz) |
20 ~ 1000Hz 0.5% |
Display |
4 digits LCD 9999 |
Power supply |
4 x 1.5V AA |
Operating temperature |
0°C ~ 40°C |
Dimensions |
300mm x 103mm x 51mm |
Weight |
Approx. 500g |
Edited by Johnny
