MS2208 Auto Range Digital Power Clamp Meter With 6000 Counts

Name: MS2208 Auto Range Digital Power Clamp Meter With 6000 Counts
Brand: Graigar
SKU: 130765803
Availability: InStock

US$ 365 - 395 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Graigar

Model Number:

MS2208

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Graigar

Model Number MS2208

Display Type Digital Only

Measuring Current Range 0A ~ 200A

Measuring Voltage Range 0V ~ 600V

Dimensions 208mm*78mm*35mm

Weight 350g

MS2208 Auto Range Digital Power Clamp Meter with 6000 Counts

Product Description

Feature
Display	6000 counts
Jaw Opening	Φ26mm/1.0”
Auto Ranging	√
MAX/MIN	MAX/MIN measurement mode
Flash Light	Pointing to the target area
Data Hold	√
Display Backlight	√
Specification	Range	Accuracy
AC Voltage(TRMS)	10V ~ 600V	±(1%+5)
AC Current(TRMS)	2mA ~ 3999mA	±(2%+5)
AC Current(TRMS)	4A ~ 200A	±(2%+5)
Single phase active power(kW)	0.1W ~ 120KW	±(3%+5)
Single phase apparent power(kVA)	0.01kVA ~ 120kVA	±(3%+5)
Single phase reactive power(kVAr)	0.01kVAr ~ 120kVAr	±(3%+5)
Power Factor	0.3~1 capacitive	±(2%+2)
Power Factor	0.3~1 inductive	±(2%+2)
Frequency(Hz)	30Hz~1kHz	±(0.5%+1)
Harmonic measurement	Harmonic number: 1	±(3.0%+10)
	Harmonic number: 2~6	±(3.5%+10)
	Harmonic number: 7~8	±(4.5%+10)
	Harmonic number: 9~10	±(5.0%+10)
	Harmonic number: 11~15	±(7.0%+10)
	Harmonic number: 16~20	±(10%+10)
