Home > Instruments & Meters > Electronic Instrument > Clamp Meter > !!Brand New!! KYORITSU KEW 2027 Digital Clamp Meters True RMS
!!Brand New!! KYORITSU KEW 2027 Digital Clamp Meters True RMS
US$ 134 - 147
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
KYORITSU
Model Number:
2027
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MS2208 Auto Range Digital Power Clamp Meter With 6000 CountsUS$ 365 - 395MOQ: 1 Piece -
MS2205 Harmonic AC DC Digital Power Clamp Meter RS232 InterfaceUS$ 190 - 250MOQ: 1 Piece
-
MS2108A 4000 Counts AC/DC Current Clamp Multimeter Meter Digital VoltmeterUS$ 30 - 40MOQ: 1 Piece
-
High Quality MS2203 3 Phase TRMS Digital Clamp Meter Power Factor Correction MultimeterUS$ 150 - 190MOQ: 1 Piece
-
High Quality MS2108 True RMS DC Current Clamp MeterUS$ 38 - 50MOQ: 1 Piece
Place of Origin
Japan
Brand Name
KYORITSU
Model Number
2027
Display Type
Digital Only
Measuring Current Range
200/600A
Measuring Voltage Range
600V
Measuring Resistance Range
200Ω
Operating Temperature
-10~50
Dimensions
208(L) x 91(W) x40(D)mm
Weight
0.4kg
!!Brand New!! KYORITSU KEW 2027 Digital Clamp Meters True RMS
| True RMS reading instrument that permits precise measurements of non-sinusoidal waveform AC current and voltage. Accurate measurements are also possible at low frequencies from 10Hz upwards. | |
| • | Designed to meet internationally proven safety standards such as IEC 61010-1, UL3111 and VDE0411. |
| • | Three functions in one unit; AC current, AC voltage and resistance. |
| AC A | 200/600A (True RMS) |±1.5%rdg±4dgt [50/60Hz] (CF<3) |±2%rdg±5dgt [40Hz~1kHz] (Sine wave) |
| AC V | 200/600V (True RMS) (CF<3) |±1.5%rdg±4dgt [50/60Hz] |±2%rdg±5dgt [40Hz~1kHz] |
| Ω | 200Ω |±1.2%rdg±4dgt |
| Continuity buzzer | buzzer sounds below 30±20Ω |
| Conductor Size | Ø33mm max. |
| Safety Standard | IEC 61010-1 CAT.III 600V Pollution Degree 2 IEC 61010-2-031 |
| Frequency Response | 40Hz~1kHz |
| Withstand Voltage | 5550V AC for 1 minute |
| Power Source | 6F22 (9V) × 1 |
| Dimensions | 208(L) × 91(W) × 40(D)mm |
| Weight | 400g approx. |
| Accessories | 7066A (Test leads) 9079 (Carrying case) 6F22 × 1 Instruction Manual |
| Optional | 8008 (Multi-Tran) |
