Home > Instruments & Meters > Electronic Instrument > Clamp Meter > MS2108A 4000 Counts AC/DC Current Clamp Multimeter Meter Digital Voltmeter
MS2108A 4000 Counts AC/DC Current Clamp Multimeter Meter Digital Voltmeter
US$ 30 - 40
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Graigar
Model Number:
MS2108A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality MS2203 3 Phase TRMS Digital Clamp Meter Power Factor Correction MultimeterUS$ 150 - 190MOQ: 1 Piece -
High Quality MS2108 True RMS DC Current Clamp MeterUS$ 38 - 50MOQ: 1 Piece
-
MS1000A Electronics High Voltage AC Digital LCR Clamp Meter MultimeterUS$ 30 - 38MOQ: 1 Piece
-
MS2108A Multimeter Digital Clamp Meter Megohmmeter Resistance Earth Tester MultimeterUS$ 32 - 40MOQ: 1 Piece
-
3 3/4 Digits AC/DC Smart True RMS Digital Clamp Multimeter MS1000BUS$ 50 - 60MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Graigar
Model Number
MS2108A
Display Type
Digital Only
Measuring Current Range
40A/400A ±2%
Measuring Voltage Range
400mV/4V/40V/400V/1000V±0.8
Measuring Resistance Range
400Ω/4KΩ/40KΩ/400KΩ±0.8% 4MΩ/40MΩ±1.2%
Dimensions
208*78*35 mm
Weight
340g
MS2108A 4000 Counts AC/DC Current Clamp Multimeter Meter Digital Voltmeter
Features:
Perform measurements of AC/DC voltage and current, resistance, capacitance, frequency, duty cycle, diode and continuity test.
Measuring frequency, AC/DC current and duty cycle by clamp.
LCD with backlight & bar graph and clamp lighting bulb.
Relative value measurement and auto range function.
Provided with one excellent cloth bag for conveniently-carrying.
Data holding, to hold the readings while taking measurement.
Maximum and minimum value measuring and holding.
Automatic indication of functions and unit symbols.
Auto power off and low battery indication.
Full overload protection and dual insulation protection.
Over-molding rubber case, shake-proof, skid-proof and good touch-feeling.
Specifications:
| General specifications: | |||
| Max. V between terminals & earth: | 1000V DC or 750V rms AC | ||
| Operating temperature: | 0 to 40 Celsius Degree (32 Fahrenheit to 104 Fahrenheit) | ||
| Storage temperature: | -10 to 50 Celsius Degree (10 Fahrenheit to 122 Fahrenheit) | ||
| Operating altitude: | Max. 2000 meters (7000 ft.) | ||
| Max. diameter for conductor: | Diameter 26mm | ||
| Max. displayed value: | 4000 digits | ||
| Auto polarity indication: | "-" for negative polarity. | ||
| Over-range indication: | "0L" or "-0L" | ||
| Converter rate: | 3 times/sec; Bar graph: 30 times/sec | ||
| Auto power off time: | 15 minute | ||
| Power supply: | 3 * 1.5V AAA battery (not included) | ||
| Multimeter size: | 20.8 * 7.8 * 3.5cm / 8.2 * 3.1 * 1.4in | ||
| Multimeter weight: | 238g / 8.4oz | ||
| Package size: | 23 * 10.5 * 6cm / 9.1 * 4.1 * 2.4in | ||
| Package weight: | 469g / 16.5oz | ||
| Measurement specifications (accuracy): | |||
| AC Current | 40A/400A | ±2.0% | |
| DC Current | 40A/400A | ±2.0% | |
| DC Voltage | 400mV | ±1.0% | |
| 4V/40V/400V | ±0.7% | ||
| 1000V | ±0.8% | ||
| AC Voltage | 4V/40V/400V | ±0.8% | |
| 750V | ±1.0% | ||
| Frequency | By A range (current clamp) | 10Hz/1kHz/>1kHz | ±1.5% |
| By ACV range | 10Hz/1kHz/10kHz | ±1.5% | |
| >10kHz | Take it only as reference | ||
| By Hz/DUTY range | 9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz | ±0.5% | |
| Resistance | 400Ω/4kΩ/40kΩ/400kΩ/4MΩ | ±0.8% | |
| 40MΩ | ±1.2% | ||
| Capacitance | 40nF/400nF/4uF/40uF/400uF/4000uF | ±4.0% | |
Package including:
1 * Digital Multimeter
2 * Test Lead
1 * Instruction Manual
