Durable Best Sell Pvdf Pleated Membrane Filter Cartridge

material of construction

filter membrane

hydrophilic & hydrophobic PVDF micropore membrane

diversion layer

pp nonwovens

housing

pp no-woven

inner support

pp or pp stainless lining

specification

OD

Φ68mm Φ69mm

ID

Φ32mm

length

2.5~40"

seal sing

silicon,EPDM,Nitrile,fluorous,PTFE with fluorous

precision

0.20,0.45,1.00μm

effective filtration

Area≥0.65m²

operation condition

PH value

1~13

normal working temperature

≤65℃

max. working temperature

90℃, Pressure differential ≤0.10Mpa

max differential pressure

25℃,forward direction 0.42Mpa,reverse direction0.21MPa

sterile condition

121±2℃ steam for 30min/once or sterilization cabinet for 30min/once.

 educt

endotoxin

<0.25EU/ml

extractive

<0.03g/10"cartridge

electronic grade

Hundred thousand grades purify workshop+ backwash with 18M ultra purify water, meets with electronic producing requirements. Inner and outer diversion layers are import PP long fiber fabric no-woven.

pharmaceutical grade

Hundred thousand grades purify workshop+ pure water backwash, which meets with GMP pharmacy standards. Inner and outer diversion layers are import PP long fiber fabric no-woven.

food grade

Hundred thousand grades purify workshop+ purify water backwash, which meets with FDA safety regulations. Inner diversion layer: import PP long fiber fabric no-woven. Outer: domestic no-woven.

i)

High flow rate with low pressure drops;

ii)

High particle removal efficiency;

iii)

Superior performance of high-temperature and acid&alkali

iv)

Easy installation, replacement and maintenance;

v)

Long service life.

i)

ISO9001:2000 certified company;

ii)

Pharmaceutical grade material;

iii)

 imported membranes(USA/Germany) or local membrane for options;

iv)

 Pharmaceutical grade workshops;(according to GMP criterion);

v)

100% Integrity test and other strict test before packing
