UNI-T UT151A Modern Digital Multimeter LCD Handheld Mini Multipurpose Meter ac dc Volt Amp Ohm Capacitance Tester
US$ 50 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
ut151a
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Professional UT205A LCD Digital 1000 Clamp Multimeters DC AC Volt Ampere Ohm Hz Auto Range Tester MetersUS$ 20 - 30MOQ: 3 Pieces -
UNI-T Automotive Digital Palm-Size Multimeter UT71C Intellgent Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto RangeUS$ 82 - 120MOQ: 1 Piece
-
UNI-T Automotive Digital Palm-Size Multimeter UT71A Intellgent Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto RangeUS$ 72 - 85MOQ: 1 Piece
-
General Digital Multimeters UNI-T UT58C Voltage Current Resistance Capacitance Temperature Meter TesterUS$ 1 - 25MOQ: 2 Pieces
-
Digital Multimeters Palm Size UNI-T Ut33c Diode & Data Hold Super Mini Pocket Multimeter Measure TemperatureUS$ 1 - 10MOQ: 5 Pieces
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
ut151a
Measuring Current Range
200μA- 20A
Measuring Voltage Range
200mV-1000V
Measuring Resistance Range
200Ω - 200MΩ
Measuring Capacitance Range
20μF/200μF
Measuring Inductance Range
none
Operating Temperature
-40 °C - 1000°C
Dimensions
186mm * 91mm * 39mm
UNI-T UT151A Modern Digital Multimeter LCD Handheld mini Multipurpose meter ac dc Volt Amp Ohm Capacitance Tester
Introduction
UT151A is stable performance, high reliability and handheld 3 1/2 digit digital multimeter, the whole circuit is designed to LSI, dual slope A / D converter as its core and with a fully functional overload protection, can be used to measuring DC and AC voltage, current, resistance, capacitance, diodes, batteries and circuit continuity. In addition, the series of instruments mA self resettable fuse gear, so that the user erroneous operation even when there is no need to replace the files in the mA fuse.
UT151A can be used to measure the family, school, smelting, telecommunications, manufacturing, oil, defense, electricity, chemical and other industries, it is the ideal tool for circuit / electrical equipment maintenance and repair.
Specification
| Specifications | Range | Best Accuracy | |
| Model | UT151A | UT151B | |
| DC Voltage (V) | 200mV/ 2V/ 20V/ 200V/ 1000V | ±(0.5%+1) | ±(0.5%+1) |
| AC Voltage (V) | 2V/ 20V/ 200V/ 750V | ± (0.8%+3) | ± (0.8%+3) |
| DC Current (A) | 200μA/ 2mA/ 200mA/ 20A | ± (0.8%+1) | ± (0.8%+1) |
| AC Current (A) | 200μA/ 2mA/ 200mA/ 20A | ± (1%+3) | ± (1%+3) |
| Resistance (Ω) | 200Ω/ 2KΩ/ 20KΩ/ 200KΩ/ 2MΩ/ 20MΩ/ 200MΩ | ±(1%+2) | ±(1%+2) |
| Capacitance (F) | 20μF/200μF | ±(5%+4) >100μF Reference Only | |
| 2nF/ 20nF/200nF/ 2μF/ 100μF | ±(4%+3) | ||
| Features | |||
| Display Count | 1999 | 1999 | |
| Manual Range | √ | √ | |
| Battery Test | 12V/ 9V/ 1.5V | ±(2.5%+2) | |
| Diode | √ | √ | |
| Auto Power Off | √ | √ | |
| Continuity Buzzer | √ | √ | |
| Low Battery Indication | √ | √ | |
| Data Hold | √ | √ | |
| Input Impedance for DCV | ≥10MΩ | √ | √ |
| General Characteristic | |||
| Power | 9V Battery(6F22) | ||
| LCD Size | 63mm * 29mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 300g | ||
| Product Size | 186mm * 91mm X39mm | ||
| Standard Accessories | Battery,Test Lead | ||
| Standard Individual Packing | Gift Box,English Manual | ||
| Standard Quantity Per Carton | 40 PCs | ||
| Standard Carton Measurement | 645mm * 450mm * 340mm (0.099 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 22.8 Kg | ||
Accessory
1.Battery, (not included)
2.Test Lead,
