Home > Instruments & Meters > Meter for Electricity > Multimeter > UNI-T Automotive Digital Palm-Size Multimeter UT71A Intellgent Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto Range
UNI-T Automotive Digital Palm-Size Multimeter UT71A Intellgent Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto Range
US$ 72 - 85
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT71A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
General Digital Multimeters UNI-T UT58C Voltage Current Resistance Capacitance Temperature Meter TesterUS$ 1 - 25MOQ: 2 Pieces -
Digital Multimeters Palm Size UNI-T Ut33c Diode & Data Hold Super Mini Pocket Multimeter Measure TemperatureUS$ 1 - 10MOQ: 5 Pieces
-
UNI-T UT513 Insulation Resistance Tester 1000ohm Digital Megger Tramegger 500V/1000V/2500V/5000V USB InterfaceUS$ 150 - 210MOQ: 1 Piece
-
Professional Modern Digital Clamp Meters UNI-T UT200A Multimeter Resistance TesterUS$ 7 - 13MOQ: 5 Pieces
-
Handheld Automotive Multi-Purpose Meters UT106 Ac/dc Voltage Current Tester MultimeterUS$ 12 - 18MOQ: 3 Pieces
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT71A
Measuring Current Range
200μA - 10A
Measuring Voltage Range
200mV - 1000V
Measuring Resistance Range
200Ω - 20MΩ
Measuring Capacitance Range
20nF - 20mF
Measuring Inductance Range
none
Operating Temperature
-40 °C - 1000°C
Dimensions
200mm * 93mm * 40 mm
UNI-T Automotive Digital Palm-Size Multimeter UT71A Intellgent Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto Range
Introduction
UT71A product is 19999 count 4 1/2 Auto range True RMS digital multimeter with analog bar graph shows a full-featured, full-range overload protection and unique design, making it more superior performance of high-precision electrical measuring instruments.
Suitable for: metallurgy, electronics, telecommunications, manufacturing, petroleum, defense, power, chemical and other industries and major colleges. Also used to solve electronics, factory automation, power distribution and electromechanical equipment of complex issues. tools.
Specification
| Specifications | Range | Best Accuracy | |
| Model | UT71A | UT71B | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.1%+8) | ±(0.05%+5) |
| AC Voltage (V) | 2V/20V/200V/1000V | ±(0.8%+40) | ±(0.6%+40) |
| DC Current (A) | 200μA/2000μA/20mA/200mA/10A | ± (0.2%+20) | ± (0.15%+20) |
| AC Current (A) | 200μA/2000μA/20mA/200mA/10A | ± (1%+15) | ± (0.8%+15) |
| Resistance (Ω) | 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ | ±(0.5%+20) | ±(0.4%+20) |
| Capacitance (F) | 20nF/200nF/2μF/20μF/200μF/2mF/20mF | ±(1.5%+20) | ±(1.2%+20) |
| Frequency (Hz) | 20Hz-200MHz | ±(0.1%+15) | ±(0.1%+15) |
| Temperature (°C) | ±(1%+30) | ||
| Temperature (°F) | ±(1.5%+50) | ||
| Features | |||
| Display Count | 19999 | 19999 | |
| Auto Range | √ | √ | |
| True RMS | √ | √ | |
| Bandwidth (Hz) | 100KHz | √ | √ |
| Duty Cycle | 10% - 90% | ±(1%+30) | ±(1%+30) |
| Diode | √ | √ | |
| Auto Power Off | √ | √ | |
| Continuity Buzzer | √ | √ | |
| Low Battery Indication | √ | √ | |
| Data Hold | √ | √ | |
| Relative Mode | √ | √ | |
| MAX/MIN | √ | √ | |
| Data Logging | 100 | ||
| USB Interface | √ | √ | |
| Double Backlight | √ | √ | |
| Analogue Bar Graph | √ | √ | |
| Full Icon Display | √ | √ | |
| Setup | √ | √ | |
| Input Impedance for DCV | DC 200mV: Around 2.5GΩ,All Other Range: 10MΩ | √ | √ |
| 4 - 20mA Loop | 0-100% | ±(1%+50) | |
| Fused 10 A | √ | √ | |
| Current Measurement Alarm | √ | √ | |
| Voltage & Current AC+DC Measurement | √ | √ | |
| General Characteristic | |||
| Power | 9V Battery(6F22) (not included) | ||
| LCD Size | 73mm * 50 mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 384g | ||
| Product Size | 200mm * 93mm * 40 mm | ||
| Standard Accessories | UT71A-Battery, Test Lead, Alligator Clip, Test Clip, USB Interface Cable,PC Software CD,Carrying Bag | ||
| UT71B-Battery, Test Lead, Alligator Clip, Test Clip, USB Interface Cable,PC Software CD,Carrying Bag, Point Contact Temperature Probe | |||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 20 PCs | ||
| Standard Carton Measurement | 530mm * 360mm * 385mm (0.073 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 22 Kg | ||
Accessory
1.Battery, (not included)
2.Test Lead,
3.Alligator Clip,
4.Test Clip,
5.USB Interface Cable,
6.PC Software CD,
7.Carrying Bag
