Home > Instruments & Meters > Electronic Instrument > Clamp Meter > Professional UT205A LCD Digital 1000 Clamp Multimeters DC AC Volt Ampere Ohm Hz Auto Range Tester Meters
Professional UT205A LCD Digital 1000 Clamp Multimeters DC AC Volt Ampere Ohm Hz Auto Range Tester Meters
US$ 20 - 30
MOQ: 3 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT205A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T Automotive Digital Palm-Size Multimeter UT71C Intellgent Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto RangeUS$ 82 - 120MOQ: 1 Piece -
UNI-T Automotive Digital Palm-Size Multimeter UT71A Intellgent Multi-Purpose Meter LCD Voltmeter Ammeter Ohmmeter Auto RangeUS$ 72 - 85MOQ: 1 Piece
-
General Digital Multimeters UNI-T UT58C Voltage Current Resistance Capacitance Temperature Meter TesterUS$ 1 - 25MOQ: 2 Pieces
-
Digital Multimeters Palm Size UNI-T Ut33c Diode & Data Hold Super Mini Pocket Multimeter Measure TemperatureUS$ 1 - 10MOQ: 5 Pieces
-
UNI-T UT513 Insulation Resistance Tester 1000ohm Digital Megger Tramegger 500V/1000V/2500V/5000V USB InterfaceUS$ 150 - 210MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT205A
Display Type
Digital Only
Measuring Current Range
400A/1000A
Measuring Voltage Range
4V/40V/400V/600V
Measuring Resistance Range
400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ
Measuring Capacitance Range
1000uF
Measuring Inductance Range
Contact
Operating Temperature
-40 °C ~ 1000°C
Dimensions
236mm X 97mm X40 mm
Weight
1kg
Professional UT205A LCD Digital 1000 Clamp Multimeters DC AC Volt Ampere Ohm Hz Auto Range Tester Meters
Introduction
UT205A is a low power consumption and stable performance, safe and reliable 3 3/4 AC digital clamp meter, full-range overload protection circuit, unique design makes it the superior performance of dedicated electrical instruments.
Used in metallurgy, manufacturing, petroleum, electricity, chemical and other industries the ideal tool for maintenance / repair.
Specification
| Specifications | Range | Best Accuracy | |
| Model | UT205A | UT206A | |
| AC Current (A) | 400A/1000A | ±(1.5%+5) | ±(1.5%+5) |
| AC Voltage (V) | 4V/40V/400V/600V | ±(1.2%+5) | ±(1.2%+5) |
| DC Voltage (V) | 400mV/4V/40V/400V/600V | ±(0.8%+1) | ±(0.8%+1) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(1%+2) | ±(1%+2) |
| Frequency (Hz) | 10Hz~10MHz | ±(0.1%+3) | ±(0.1%+3) |
| Temperature (°C) | -40 °C ~ 1000°C | ±(2%+8) | |
| Features | |||
| Display Count | 4000 | 4000 | |
| Auto Range | √ | √ | |
| Jaw Capacity | 40mm | 40mm | |
| Duty Cycle | 0.1%~99.9% | √ | |
| Diode | √ | √ | |
| Auto Power Off | √ | √ | |
| Continuity Buzzer | √ | √ | |
| Low Battery Indication | √ | √ | |
| Data Hold | √ | √ | |
| Relative Mode | √ | ||
| LCD Backlight | √ | √ | |
| Full Icon Display | √ | √ | |
| Input Impedance for DCV | Around 10MΩ | √ | √ |
| General Characteristic | |||
| Power | 9V Battery(6F22) | ||
| LCD Size | 37mm X 18 mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 350g | ||
| Product Size | 236mm X 97mm X40 mm | ||
| Standard Accessories | UT205A-Battery, Test Lead,Carrying Bag | ||
| UT206A-Battery, Test Lead,Carrying Bag,Point Contact Temperature Probe | |||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 20 PCs | ||
| Standard Carton Measurement | 530mm X 360mm X 385mm (0.073 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 17Kg | ||
Accessory
1. Battery,(not included)
2. Test Lead,
3. Carrying Bag
