Home > Products > Electrical Instruments > General Digital Multimeters UNI-T UT58C Voltage Current Resistance Capacitance Temperature Meter Tester
General Digital Multimeters UNI-T UT58C Voltage Current Resistance Capacitance Temperature Meter Tester
USD $1 - $25
/ Piece
2 Pieces(Min.Order)
- 500 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
Acrel AMC16Z-FAK48 Electric Module Multi Channel Current Detection Module For Data Center Precision Cabinet
-
Acrel AMC16Z-FAK48 Electric Muti channel Monitoring Module Data Center Precision Cabinet
-
Acrel AMC16Z-FAK48 Electric Muti Channel Monitoring Module Data Center Precision Cabinet
-
48 Circuit Monitoring Data Center Monitor Power Supply Management Server Multi Loop Energy Meter AMC16Z-FAK48
-
Acrel AMC16Z-FAK48 Electric Muti Channel Monitoring Module Data Center Precision Cabinet
-
Din Rail Ac Power Meter AMC16Z-FAK48 Multi-circuit Energy Meter One RS485 Communication 48 Branch Full Electric Parameter
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | UNI-T | Model Number: | UT58C |
| Measuring Current Range: | 2000μA/20mA/200mA/10A | Measuring Voltage Range: | 200mV/2000mV/20V/200V/500V | Measuring Resistance Range: | 200Ω/2000Ω/20kΩ/200kΩ/20MΩ |
| Measuring Capacitance Range: | none | Measuring Inductance Range: | none | Operating Temperature: | -40 °C - 1000°C |
| Dimensions: | 130mm*73.5mm*35mm |
Product Description
General Digital Multimeters UNI-T UT58C Voltage Current Resistance Capacitance Temperature Meter Tester
Introduction
UT58C 1999 count 3 1/2 digit digital multimeter manual range. It has a large screen, full-featured symbol display and input connections prompt, full scale overload protection and unique design, making it more superior performance of electrical instruments.
Can be used to measure AC and DC voltage, DC current, resistance, temperature, frequency, diode forward voltage drop and circuit continuity, is ideal for the majority of users to carry maintenance tools.
Specification
| Specifications | Range | Best Accuracy | ||
| Model | UT58A | UT58B | UT58C | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.5%+1) | ±(0.5%+1) | ±(0.5%+1) |
| AC Voltage (V) | 2V/20V/200V/750V | ±(0.8%+3 | ±(0.8%+3 | ±(0.8%+3 |
| DC Current (A) | 20μA/2mA/20mA/200mA/20A | ±(0.8%+1) | ||
| 2mA/20mA/200mA/20A | ±(0.8%+1) | |||
| 2mA/200mA/20A | ±(0.8%+1) | |||
| AC Current (A) | 2mA/200mA/20A | ±(1%+3) | ±(1%+3) | ±(1%+3) |
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/2MΩ/20MΩ/200MΩ | ±(0.8%+1) | ±(0.8%+1) | |
| 200Ω/2kΩ/20kΩ/2MΩ/20MΩ | ±(0.8%+1) | |||
| Capacitance (F) | 2nF/200nF/100μF | ±(4%+3) | ±(4%+3) | ±(4%+3) |
| Frequency (Hz) | 2kHz/20kHz | ±(1.5%+5) | ||
| Temperature (°C) | -40 °C - 1000°C | ±(1%+3) | ±(1%+3) | |
| Features | ||||
| Display Count | 2000 | 2000 | 2000 | |
| Manual Range | √ | √ | √ | |
| Diode | √ | √ | √ | |
| Transistor | √ | √ | √ | |
| Auto Power Off | √ | √ | √ | |
| Continuity Buzzer | √ | √ | √ | |
| Data Hold | √ | √ | √ | |
| Low Battery Indication | √ | √ | √ | |
| Full Icon Display | √ | √ | √ | |
| Input Impedance for DCV | Around 10MΩ | √ | √ | √ |
| Test Lead Connection Indications | √ | √ | √ | |
| General Characteristic | ||||
| Power | 9V Battery96F22) (not included) | |||
| LCD Size | 60×54mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 350g (Including holster) | |||
| Product Size | 179mm*88mm*39mm | |||
| Standard Accessories | UT58A-Battery, Test Lead,Holster,Muli-Purpose Socket | |||
| UT58B/UT58C-Battery, Test Lead,Holster,Muli-Purpose Socket,Point Contact Temperature Probe | ||||
| Standard Individual Packing | Gift Box, English Manual | |||
| Standard Quantity Per Carton | 40 PCs | |||
| Standard Carton Measurement | 598*418*340mm (0.085 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 27 Kg | |||
Accessory
1. Battery, (not included)
2. Test Lead,
3. Holster,
4. Muli-Purpose Socket,
5. Point Contact Temperature Probe
