no harm 4-20mA rigid oil green melt pressure transmitter
- 8000 Piece / Pieces per Month
- Shanghai
- T/T L/C Credit Card PayPal
- mpa explosion proof electric contact pressure gauge types
- Tuning fork level switch of DC 24V
- China Factory Manufacturing High Quality High Accuracy small Digital Temperature and Pressure Integral Sensor
- China Factory Manufacturing High Quality High Accuracy small pressure sensor 0-10V 0.5-4.5V 4-20mA Hydraulic oil Pressure sensor
- China Factory Manufacturing High Quality High Accuracy small 0-10V 0.5-4.5V 4-20mA Hydraulic oil pressure sensor
- China Factory Manufacturing High Quality High Accuracy small Pressure Transmitter 0-10V 0.5-4.5V 4-20mA Pressure sensor
Product Details
Place of Origin: | Shanghai, China | Brand Name: | ZHYQ | Model Number: | PT124B-113 |
Product Description
Description
PT124B-113 is no harm 4-20mA rigid oil green melt pressure transmitter , this series is mercury free (oil filled ) melt pressure transmitter , this melt pressure transmitter is designed with rigid stem ,oil filled , avirulent medium ,sanitary pressure sensor , If the the melt pressure transmitter diaphragm damaged during process, the leaking medium is no harm to the human body or ambient; and built in 80% shunt calibration , can match the N series pressure instrument from ZHYQ, also this melt pressure transmitter can match the pressure instrument or controller of other brand; all our melt pressure transmitter is international standard output ,the signal can be connected with PLC directly , and can replace Dynisco or Gefran products absolutely .
Feature
mercury free melt pressure transmitter
High-standard performance quality
Stainless steel welding ,Simple installation
oill filled ,environmental and non-toxic material
80% internal calibration Excellent stability and repeatability
Application
sanitary medicine & food process equipment
drinking water enviromental monitoring
industrial testing and controlling
automatic testing system
Chemical fiber Equipment
Plastic and Rubber manufacturing equipment
Medicine & Food process equipment, etc
Specification
Name | no harm 4-20mA rigid oil green melt pressure transmitter |
Model | PT124B-113 |
Pressure range | 0-10MPa…0-150MPa (0-1500psi…0-20000psi) |
Over Pressure | 1.5 X FSO |
Combined Error | ± 1.5% FSO; ± 1.0% FSO (Including Linearity, Repeatability & Hysteresis) |
Output | 4-20mA, 0-10V, 0-5V |
Input Voltage | 24VDC |
Repeatability | +/- 0.2%FSO |
Internal Shunt Calibration (R-Cal) | 80% FSO +/- 1% |
Insulation Resistance | 200 megohms @ 100 Vdc |
Max Diaphragm Temperature | 260 °C |
Mounting Torque | 500 inch/lbs. max. |
Standard Wetted Parts | Diaphragm coated 15-5 PH SST |
Process connector | 1/2 ″ -20UNF, M14×1.5, M18×1.5 Optional |
Dimension
PT124B-113
Order Guide : with "* "are required , with "---"is optional
Model | Range | output | Rigid & flexible length (inch) | Screw Thread | Electric connector | Accuracy | others |
PT124B-113 | * | * | * | * | * | * | --- |
Example:PT124B-113-500Bar-4-20mA -6”-1/2-20UNF-5PIN-0.5% |
This no harm 4-20mA rigid oil green melt pressure transmitter
Our products are widely used in the field of hydraulic pressure, air pressure, petrochemical industry, automotive, air condition and compressor, construction machinery, plastic extrusion, chemical fiber, plastic rubber machine, non-woven fabrics and etc.
ZHYQ has a strong R&D team with more than 10 staffs, there are 3 senior engineers, 5 intermediate engineers, in the major of mechatronics. They have successfully developed a lot of new and High-tech products, won a number of patents and awards.
can matching with our N series digital pressure indicator
