Help Center4 Color PP Woven Sack Printing Machine (Changhong)
Related Products
-
Changhong 6 Color PP Woven Sack Printing MachineUS$ 20,000 - 80,000MOQ: 1 Set -
Changhong Brand 6 Color PP Woven Bag Flexo Printing MachineUS$ 20,000 - 70,000MOQ: 1 Set
-
Changhong 4/6 Color PP Woven Bag Flexographic Printing MachineUS$ 25,000 - 60,000MOQ: 1 Set
-
Changhong 6 Color PP Woven Bag Flexographic Printing MachineUS$ 20,000 - 60,000MOQ: 1 Set
-
Changhong 6 Color PP Woven Bag Flexographic Printing MachineUS$ 20,000 - 50,000MOQ: 1 Set
The main features:
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8 With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Print produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll
Main Technical Parameter:
Printing width Item |
600mm |
800mm |
1000mm |
1200mm |
1400mm |
1600mm |
1800mm |
2000mm |
Printing material |
Weave Cloth,Single filter membrance PP Weave Cloth,Double filter membrance PP Weave Cloth |
|||||||
Printing color |
4 Color |
|||||||
Printing length |
7.5"-50" (90mm-1270mm) |
|||||||
Printing plate lifting system |
Hydraulic press control |
|||||||
Mechanical speed |
90m/min |
|||||||
Printing speed |
10-70m/min |
|||||||
Register precision |
Longitude:±0.2mm Transverse: ±0.2mm |
|||||||
Rewinder/Unwinder DIA |
ø 1200mm |
|||||||
Weight |
3750Kg |
4000 Kg |
4300 Kg |
4600 Kg |
5000 Kg |
5500 Kg |
6000 Kg |
6500 Kg |
Dimension (L×W×H) |
6.2m |
6.3m |
6.4m |
6.5m |
6.6m |
6.7m |
6.8m |
6.9m |
1 Year Guarantee !
100% Good Quality !
24 Hours online Service!
