Help CenterChanghong 4 Color Paper Flexographic Printing Machine
Related Products
-
Changhong 4 Color Thermal Paper Flexo Printing MachineUS$ 25,000 - 80,000MOQ: 1 Set -
Changhong Brand 4 Color Paper Roll to Roll Flexo Printing MachineUS$ 15,000 - 50,000MOQ: 1 Set
-
Changhong 4 Color Paper Cup Roll Printing MachineUS$ 15,000 - 50,000MOQ: 1 Set
-
Changhong High Speed 6 Color Paper Flexo Printing MachineUS$ 15,000 - 50,000MOQ: 1 Set
-
6 Color Paper Coffee Cup Printing MachineUS$ 15,000 - 70,000MOQ: 1 Set
4 Colour Paper Flexography Printing Press(CH884)
The main features:
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8 With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Print produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll
Main Technical Parameter:
Model |
CH884-600P |
CH884-800P |
CH884-1000P |
CH884-1200P |
CH884-1400P |
CH884-1600P |
Max. Material width |
650mm |
850mm |
1050mm |
1250mm |
1450mm |
1650mm |
Max. Printing width |
560mm |
760mm |
960mm |
1160mm |
1360mm |
1560mm |
Printing material |
Single adhesive paper,Double adhesive paper,Copper plate paper,Kraft paper :50-350g/m2 Single filter membrance paper,Double filter membrance paper : 80-350g/m2 |
|||||
Printing color |
4 special color |
|||||
Printing length |
7.5"-40" (90mm-1016mm)/7.5"-50"(90mm-1270mm) |
|||||
Printing plate lifting system |
Hydraulic press control |
|||||
Mechanical speed |
90m/min |
|||||
Printing speed |
10-70m/min |
|||||
Anilox roller |
Metal: 100-300LPI Or Ceramic anilx roller(200-1000LPI), single doctor blade |
|||||
Rewinder/Unwinder DIA |
ø 1000mm /ø 1200mm /ø 1500mm |
|||||
Master power |
28KW |
30KW |
32KW |
35KW |
38KW |
40KW |
Weight |
5000Kg |
5200Kg |
5600 Kg |
6000 Kg |
6200Kg |
6500Kg |
Dimension |
5.2m ×2.0m × 2.5m |
5.2m × 2.2m× 2.5m |
5.3m × 2.4m ×2.5m |
5.3m × 2.6m × 2.6m |
5.4m × 2.8m × 2.6m |
5.4m × 3.0m × 2.6m |
1 Year Guarantee !
100% Good Quality !
24 Hours online Service!
