Vertical Fine Boring Machine T170,200,250a
Charicteristics
Stepless of spindle turning ,feeding
Rotating speed and feed of spindle is free-setup, automatical retuming of spindle can be realized
Longitudingal and cross movement of table
Complete set of accessories of boring, drilling & reaming and easy exchange
Spindle fast centering device
Tool mwasuring device
Boring depth control device
Table with digital readout for jig borer machine
Specifications
ITEMS |
|
T170A |
T200A |
T250A |
|
Max. boring diameter |
Mm |
170 |
200 |
250 |
|
Max. boring depth |
Mm |
400 |
500 |
500 |
|
Max. drilling& reaming diameter |
Mm |
φ30 |
|||
Spindle speed |
r/min |
120-860 |
|||
Feeding of the spindle |
Mm/min |
14-900 |
|||
Rapid moving speed of the spindle |
Mm/mim |
900 |
|||
Spindle travel |
Mm |
700 |
|||
Distance between spindle end face and table |
Mm |
0-700 |
|||
Distance between spindle axis and carriage vertical plane |
Mm |
350 |
|||
Max. longitudinal travel of the working table |
Mm |
1500 |
|||
Max. cross travel of the working table |
Mm |
200 |
|||
Worktable size(W*L) |
Mm |
500*1250 |
500*1500 |
500*1500 |
|
Quantity of “T” slot |
Qua. |
5 |
|||
Dimensional precision of boring hole |
|
H7 |
|||
Machining precision |
Roundness |
Mm |
0.005 |
||
Cylindricity |
Mm |
0.01/300 |
|||
Boring surface roughness |
Um |
Ra2.5 |
|||
Main motor power |
Kw |
3 |
|||
Overall dimensions (L*W*H) |
Cm |
260*163*230 |
|||
Packing dimensions(L*W*H) |
Cm |
225*190*227 |
|||
N.W./G.W |
kg |
3300/3600 |
3500/3800 |
3500/3800 |
|
Remark |
You can buy relative accessories to upgrade your machine. |
||||
