NEW CE,ISO Cylinder Boring-Milling Machine BM150

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

CNC or Not:

Normal

Brand Name:

aps

Shaanxi APS Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not Normal

Brand Name aps

Model Number 220/380/415v

Certification ISO90001

After-sales Service Provided Engineers available to service machinery overseas

Cylinder Boring-Milling Machine BM150

Characteristics:

This machine is mainly used for repair small-middle sized engine blocks and head;easy to operation;

6 shift speed change from gear transmission box; avoid the torque lose;

Cutter pouch spindle and the spindle holder, provide high accurate and efficiency.

Centralized lubricate system ensure the long life for the machine use and easy for maintenance;

multi-choice of accessories, boring, milling, are all available. As well as motor-cycle blocks.

Specification:

Model	BM150
Boring capacity	Φ31-Φ150 mm
Max.boring depth	350 mm
Max. milling width	300 mm
Max. milling area	300x800 mm
Max. spindle head travel	530 mm
Distance from spindle C/L to column ways	335 mm
Useful table surface	400x1000 mm
Max. table traverse	830 mm
Max. table cross traverse	60 mm
Spindle rotation speeds	105, 210, 280, 390, 550, 780 rpm
Spindle head work feed speed, per revolution	0.06, 0.12,0.18 mm
Spindle head fast feed, up and down, per minute	1200 mm
Table work feed speed, per minute	52,104 mm
Spindle head work feed and spindle rotation	1.5 kw / 1.2 kw
Fast spindle head traverse, up and down	0.09 kw
Table traverse	0.19 kw
Tool grinder	0.2 kw
Overall dimension:	2570 x 1175 x1920mm
Packing dimension:	1710 x 1450 x2200mm
N.W / G.W	1700 /1950 kg
