75 Ohms RG 59 Power Cable Coaxial Cable

75 Ohms RG 59 Power Cable Coaxial Cable thumbnail-1
75 Ohms RG 59 Power Cable Coaxial Cable photo-1
US$ 0.05 - 0.25 MOQ: 50 Kilometers
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Luhua or OEM
Model Number:
RG59 coaxial cable cctv cable for surveillance camera
Contact Supplier Request Quote Chat Now
Zhejiang Luhua Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Nanjing/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Luhua or OEM
Model Number RG59 coaxial cable cctv cable for surveillance camera
Type Coaxial
Number of Conductors 1

Specifications

rg 59 coaxial cable
solid bare copper conductor
Insulation:solid PE or physical foam PE
Sheath:PVC
1.5GHz 75ohm GY/T135

Product Description

 coaxial cable RG59 in communication cables



RG59 Series Drop Coaxial cable specifications

Physical Specifications

Nominal Dimensions

Standard



Tri-shielding



Quad-shielding



Conductor

0.81mm( 0.032 in)

0.81mm( 0.032 in)

0.81mm( 0.032 in)

Dielectric

3.66mm(0.144 in)

3.66mm(0.144 in)

3.66mm(0.144 in)

Shielding 1

Al /Pet foil

Bonded Al /Pet foil

Bonded Al /Pet foil

Shielding 2

0.12mm*48( 40% coverage)

0.12mm*64( 60% coverage)

0.12mm*112( 90% coverage)

Shielding 3

-

Al /Pet foil

Al /Pet/Al foil

Shielding 4

-



0.12mm*64( 60% coverage)

Jacket

6.1mm( 0.24 in)

6.1mm( 0.24 in)

6.73mm( 0.265 in)

Messenger

  1.3mm (0.051 in) Zinc plated steel

Mechanical Characteristics

Mechanical Breaking Strength of Messenger 0.051 inch 185lbs.   823 N

Electrical Characteristics

Impedance ( Ohms)                 75±3

Nominal Capacitance (pF/m)          53

Velocity of Propagation              85%

Structural return loss (Db)≥   VHF   22

                          UHF   20

Attenuation [@68F.(20 Degree centigrade)]

Frequency Mhz

dB/100 ft

dB/100 M

5

0.86

2.82

55

2.05

6.73

211

3.80

12.47

300

4.45

14.60

400

5.10

16.73

450

5.4

17.72

550

5.95

19.52

750

6.97

22.87

865

7.52

24.67

1000

8.12

26.64



Power wire:

-- 2C/18AWG :  2C*7/0.38mm BC  + 2.17mm PVC Insulation + 5.0mm PVC Jacket



                                  Customers'  specifications are wellcomed





production process

75 ohms RG 59 power cable coaxial cable

Packaging & Shipping

305m/wooden reel/carton box
500/wooden reel/carton box
or according to the customer request

75 ohms RG 59 power cable coaxial cable

Our Services

Sample for free

1. Your inquiry will be replied in 24hours.

2. 15 years Coaxial Cable's experience,can become your professional purchasing partner.

3. OEM&ODM, any your customized cables we can help you to design and put into product .

4. Sample you need so that to test our company 's ability, we are so glad to free offer it.

5. Protection of your sales area, ideas of design and all your private information is our duty

Company Information

      Hangzhou Linan Luhua Industrial Co.,LTD.  A  more than 20-year professional manufacturer of coaxial cable products with  High Quality Cheaper Price.



Feel free to contact us when you have any problems about the products. Calls, letters, visits are welcomed.



75 ohms RG 59 power cable coaxial cable



more products



1) Mil-C-17 Standard Cable: RG6AU, RG59BU, RG11AU, RG58AU, etc.

2) RG Type 50ohm Coaxial Cable: RG8, RG58, RG174, RG213, RG214, etc.

3) RG Type 75ohm Coaxial Cable: RG59, RG6, RG7, RG11, etc

4) Trunk Cable: QR320. QR540, P3.412, P3.500, P3.565, etc.

5) RF Coaxial Cable LMR: LMR195, LMR200, LMR300, LMR400, LMR500 etc.

6) RF Coaxial Cable D-FB: 3D-FB, 5D-FB, 7D-FB, 8D-FB, 10D-FB, 12D-FB, etc.

7) Combined Cable: RG59+2C, RG6+2C, RG6+CAT5e, 2RG6+2CAT5e

8) Network Cable, LAN Cable: CAT3, CAT5, CAT5e, CAT6, Multi Pairs,

9) JIS Standard Cable: 3C-2V, 3C-2VR, 4C-2V, 5C-2V, 7C-2V, 3D-2V, 5D-2V, etc.

10) French Standard Cable: 11VAtc/PAtC, 17VAtc/PAtC, 19VAtc/PAtC, 21VAtc/PAtC,   KX6/A, KX8, etc.

11) British Standard Cable: BT3002, BT3002*8, BT3002*16, CT100, CT125, CT165, CT167, URM57, URM67, etc
