Help CenterComposite Cable CAT 5e+2/18 AWG Siamese Cable+RG59 Solid Copper
Related Products
-
Coaxial Cable RG6 + FTP for CATV, CCTV, MATV, Ethernet, Satellite SystemUS$ 0.29 - 0.78MOQ: 50 Kilometers -
RG59/RG6/CAT5E With Power Cable Siamese Cable for CCTV Camera &DVRUS$ 0.05 - 0.25MOQ: 20 Kilometers
-
Digital Multmedia Cable RG6 Coaxial Cable +CAT5e Hybird CableUS$ 0.05 - 0.25MOQ: 50 Kilometers
-
Siamese Cable RG59 +2 Power Wires for CCTV Connection DiagramUS$ 0.05 - 0.25MOQ: 50 Kilometers
-
Coaxial Cable RG59 With Two Power for Video Camera CCTV System Security Cable CE RoHS ISO9001 ApprovedUS$ 0.15 - 0.45MOQ: 50 Kilometers
Specifications
composite cable CAT 5e+2/18 AWG Siamese cable+RG591.15 year experience
2.ISO9001,CE,ROHS
3.OEM, and competitive price
Products Description
1.OEM/ODM
2.24AWG The best cost-effective
3.15 years lan cable experience
4. ISO9001/CE/ROHS/UL
5. CAT 5e,CAT6 network cable lan cable
BC: Bare Copper CCS: Copper Clad Steel
CCA: Copper Clad Aluminium P: Pairs
specifaications :
1) CAT5e:4P*0.50mm BC Conductor+0.91mm PE Insulation+5.1mm PVC Jacket
2) Customers' specifications are welcomed.
details:
Conductor:
Material:Bare copper Number of pairs:4pairs AWG:24awg Conductor diameter:
CAT5e :0.515±0.003mm Material:HDPE and FRPE Diameter: CAT5e 0.91±0.005mm
First screen:aluminum mylar shield(superposition rate:25%)
Overall screen:80/0.1mm TC braid shied(coverage:60%)
Braiding shield(48/64/96/112x0.12mm or 0.15mm or 0.16mm,braid material,AL-MG,CCA,CCS,copper or tinned copper for braid),FR/PVC or LSOH jacket
Jacket rip cord:optional
RG59 Series Drop Coaxial cable specifications
Physical Specifications
Nominal Dimensions |
Standard
|
Tri-shielding
|
Quad-shielding
|
Conductor |
0.81mm( 0.032 in) |
0.81mm( 0.032 in) |
0.81mm( 0.032 in) |
Dielectric |
3.66mm(0.144 in) |
3.66mm(0.144 in) |
3.66mm(0.144 in) |
Shielding 1 |
Al /Pet foil |
Bonded Al /Pet foil |
Bonded Al /Pet foil |
Shielding 2 |
0.12mm*48( 40% coverage) |
0.12mm*64( 60% coverage) |
0.12mm*112( 90% coverage) |
Shielding 3 |
- |
Al /Pet foil |
Al /Pet/Al foil |
Shielding 4 |
- |
|
0.12mm*64( 60% coverage) |
Jacket |
6.1mm( 0.24 in) |
6.1mm( 0.24 in) |
6.73mm( 0.265 in) |
Messenger |
1.3mm (0.051 in) Zinc plated steel |
||
Mechanical Characteristics
Mechanical Breaking Strength of Messenger 0.051 inch 185lbs. 823 N
Electrical Characteristics
Impedance ( Ohms) 75±3
Nominal Capacitance (pF/m) 53
Velocity of Propagation 85%
Structural return loss (Db)≥ VHF 22
UHF 20
Attenuation [@68F.(20 Degree centigrade)]
Frequency Mhz |
dB/100 ft |
dB/100 M |
5 |
0.86 |
2.82 |
55 |
2.05 |
6.73 |
211 |
3.80 |
12.47 |
300 |
4.45 |
14.60 |
400 |
5.10 |
16.73 |
450 |
5.4 |
17.72 |
550 |
5.95 |
19.52 |
750 |
6.97 |
22.87 |
865 |
7.52 |
24.67 |
1000 |
8.12 |
26.64 |
Power wire:
-- 2C/18AWG : 2C*7/0.38mm BC + 2.17mm PVC Insulation + 5.0mm PVC Jacket
Production Progress
Paking & Shipping
1.305m/wooden reel/carton box
2.500/wooden reel/carton box
or according to the customer request
Our Service
Sample for free
1. Your inquiry will be replied in 24hours.
2. 15 years Coaxial Cable's experience,can become your professional purchasing partner.
3. OEM&ODM, any your customized cables we can help you to design and put into product .
4. Sample you need so that to test our company 's ability, we are so glad to free offer it.
5. Protection of your sales area, ideas of design and all your private information is our duty
Company Overview
Hangzhou LinAn LuHua Industrial Co.,Ltd has more than15 years experience both in the production of coaxial cable.
We are always promoting the development of the enterprise with the Honest Operation since we step into the cable industry, so as to develop our company from a small workshop of more than 10 people to a limited company of more than 100 people.
types:
1)RG59,RG6,RG7,RG11, 75 OhmCoaxial Cable with Solid Polyethylene Insulation ,which is also named Vedio. cable
2)RG59,RG6,RG7,RG11, 75 Ohms Coaxial Cable with Gas-injected Foam Polyethylene Insulation, which is also named RF cable.
We believe that Chinese enterprise have the potential to accept the challenges, so can our company. Feel free to contact us when you have any problems about the products. Calls, letters, visits are welcomed.
