Specifications
tv cable for CAM2.MINI 6pin F to F & DC power (2.1)m-f
3.Length is 20M
cables for security system cctv cable
Products Description
RG59 Series Drop Coaxial cable specifications
Physical Specifications
Nominal Dimensions |
Standard
|
Tri-shielding
|
Quad-shielding
|
Conductor |
0.81mm( 0.032 in) |
0.81mm( 0.032 in) |
0.81mm( 0.032 in) |
Dielectric |
3.66mm(0.144 in) |
3.66mm(0.144 in) |
3.66mm(0.144 in) |
Shielding 1 |
Al /Pet foil |
Bonded Al /Pet foil |
Bonded Al /Pet foil |
Shielding 2 |
0.12mm*48( 40% coverage) |
0.12mm*64( 60% coverage) |
0.12mm*112( 90% coverage) |
Shielding 3 |
- |
Al /Pet foil |
Al /Pet/Al foil |
Shielding 4 |
- |
|
0.12mm*64( 60% coverage) |
Jacket |
6.1mm( 0.24 in) |
6.1mm( 0.24 in) |
6.73mm( 0.265 in) |
Messenger |
1.3mm (0.051 in) Zinc plated steel |
||
Mechanical Characteristics
Mechanical Breaking Strength of Messenger 0.051 inch 185lbs. 823 N
Electrical Characteristics
Impedance ( Ohms) 75±3
Nominal Capacitance (pF/m) 53
Velocity of Propagation 85%
Structural return loss (Db)≥ VHF 22
UHF 20
Attenuation [@68F.(20 Degree centigrade)]
Frequency Mhz |
dB/100 ft |
dB/100 M |
5 |
0.86 |
2.82 |
55 |
2.05 |
6.73 |
211 |
3.80 |
12.47 |
300 |
4.45 |
14.60 |
400 |
5.10 |
16.73 |
450 |
5.4 |
17.72 |
550 |
5.95 |
19.52 |
750 |
6.97 |
22.87 |
865 |
7.52 |
24.67 |
1000 |
8.12 |
26.64 |
Power wire:
-- 2C/18AWG : 2C*7/0.38mm BC + 2.17mm PVC Insulation + 5.0mm PVC Jacket
Customers' specifications are wellcomed
production process
1.305m/wooden reel/carton box
2.500/wooden reel/carton box
or according to the customer request
Paking & Shipping
COXIAL CABLE:
75 OHM: RG6 RG59 RG11 QR540
50 OHM: LMER200,300,400,600
RG58 RG8 RG213, 214, 223
SERIES OF D-FB
COMPOSE CABLE, such as RG59+power cable, RG6+power cable,etc
LAN CABLE:UTP/FTP/SFTP CAT5E, CAT6
TELEPHONE CABLE
