L1364AG Turning Machining

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

CNC Machining or Not:

Not CNC Machining

Type:

Turning

Material Capabilities:

Hardened Metals, Precious Metals, Stainless Steel

Extreme Machinery Manufacture Co., Ltd. (Jingjiang)

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

CNC Machining or Not Not CNC Machining

Type Turning

Material Capabilities Hardened Metals, Precious Metals, Stainless Steel

Place of Origin Jiangsu, China

Model Number L1364AG

Brand Name EMM

Specifications

1. long life
2.low noise.
3.high rigidity and precision

L1364AG turning machining

Feature

1-Hardened and grinded bed way and gears in headstock are with long life and low noise.

2-Spindle system is of high rigidity and precision.

3-The machine have powerful headstock gear train, high rotating accuracy and smooth running with low noise.

4-An overload safety device is provided on the apron.

5-Has a pedal or an electromagnetic braking device.

Main specification

Model Item			L1364AG
Max. swing diameter	Over bed	mm	Ø360
	Over carriage	mm	Ø195
	In gap	mm	Ø530
Max. length of workpiece		mm	1000
Effective gap length		mm	200
Spindle	Spindle bore	mm	Ø40orØ52
	Taper of bore		M.T.No.5 or M.T.No.6
	Number of speeds		12
	Range of speeds	r.p.m	40-1800
Thread cutting	Metric Range/No.		0.5~20mm/24
	Whitworth Range/No.		72~1-5/8t.p.i/61
	D.P. Range/No.		96~3-1/4D.p/45
	Module Range/No.		0.25~10M.P/20
Range of feeds	Longitudinal	mm	0.04-2.46(0.0015"-0.0913")
Range of feeds	Cross	mm	0.03-1.23(0.0006"-0.0365")
Tailstock sleeve	External diameter	mm	Ø60
	Taper of bore	mm	M.T.No.4
	Max. traverse	mm	120
Max. travel of compound rest		mm	100
Max. cross slide travel		mm	210
Max. size of tool shank(W×H)		mm	20×20
Power of main motor(double speeds)		kw	3/4
Overall dimensions(L×W×H)		mm	2360×1000×1200
Net weight		kg	1760
