EMMCHINA S222 automatic electric pipe threading machine
| Main features | Processed pipe thread diameter range | 190-320mm |
| Max.swing over bed | 1000mm | |
| Max.swing over carriage | 610mm | |
| piece length | 1700mm, | |
| Max taper | 1:04 | |
| Max stroke of taper bar | 1000mm | |
| Windth of bed | 755mm | |
| Main Drive System | Spindle bore | 330mm |
| Steps of reverse spindle speed | 9 | |
| Range of reverse spindle speed | 7.5-280r/min | |
| Feed system | Longitudinal feed kinds and scope | 32 kinds/0.1-1.5mm |
| Transverse feeding kinds and scope | 32 kinds/0.05-0.75mm | |
| Thread metric No/Range | 23 kinds/1-15mm | |
| Thread whitworth No/Range | 22 kinds/2-28 teeth/inch | |
| Pinth of screw | 2 inch | |
| bed saddle fast moving speed | 3740mm/min | |
| Tool post longitudinal fast moving speed | 1870mm/min | |
| vertical distance from the center line of the main shaft to cutting tool installation datum |
48mm | |
| tool post | Cutting tools section size | 45x45mm |
| Max.travel of bottom slide | 520mm | |
| Max.stroke of Compound rest | 300mm | |
| Swing angle of tool post | ±90º | |
| Tailstock | Dia of sleeve | 140mm |
| Taper of sleeve | Morse 6 | |
| Sleeve stroke | 300mm | |
| Lateral movement range | ±25mm | |
| Power system | Main motor | Y180L-4-B3 22KW 1470r/min |
| Rapid feed motor power | JC021-2-T2 1.5KW 2850r/min | |
| clamping motor | Y100L2-4-B5 3KW 1420r/min | |
| Cooling pumps | JCB-45 0.15KW 22L/min | |
| Gear pump | CB-B10 2.5MPa 1450r/min | |
| Machine | Overall dimensions(L*W*H) | 5000×2100×1600mm |
| Weight | 11500kg |
EMMCHINA S222 automatic electric pipe threading machine
Presale Service
We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the
warranty, we only charge for the basic costs of parts.
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
4. Provide the spare parts at cos
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in our customer needs.
EMMCHINA S222 automatic electric pipe threading machine
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
1. 100% by T/T. 100% by L/C at sight;
