VMC180 Small Cnc Turning Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Vertical

Place of Origin:

Jiangsu, China

Extreme Machinery Manufacture Co., Ltd. (Jingjiang)

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Vertical

Place of Origin Jiangsu, China

Brand Name EMM

Model Number VMC180

Voltage 380v/220v/415v

Power(W) 7500/11000

Dimension(L*W*H) 2400*2110*2800

Weight 5000kg

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.suitable for heavy load cutting
c vertical machining center
3.Adequate workplace cooling system

VMC180 small cnc turning machine

Product Features:

·With high speed. Accuracy and rigidity as well as temperature stable increasing spindle system.

·Super grade lubricating grease for spindle bearings ensure its long service life.

·Spindle hole is equipped with air-blowing device for cleaning.

·Rectangular guide ways of X. Y. Z and Z axes with good resistance against

vibration and impact are suitable for heavy load cutting, finish and rough machining.

·Adequate workplace cooling system.

Items	VMC180
X travel	mm	800
Y travel	mm	450
Z travel	mm	550
Distance between spindle center and column guide way	mm	550
Distance between spindle end and table	mm	150-700

Table size	mm	950*460
Max. table load	kg	600
T-slot(widthnumberspace)	mm	183150

Taper bore of Spindle		B-T40
Spindle speed	rpm	8000
Main motor power	kW	7.5/11
Cutter removal from spindle		Pneumatic

X. Y travel	m/min	0-16
Z travel speed	m/min	0-16
X. Y. Z Mot	Nm	12
Repeatability(X/Y/Z)	mm	±0.003

Tool number		Vertical type: 24 Horizontal type: 20
Max. tool size(with adjacent tool)	mm	Φ 80(Vertical type) Φ 90(Horizontal type)
Max. tool size(without adjacent tool)	mm	Φ 130(Vertical type) Φ 150(Horizontal type)
Max. tool length	mm	Φ 300(Vertical type) Φ250(Horizontal type)
Max. tool weight	kg	7 (Vertical type) 8 (Horizontal type)
Toll changing time(cut to cut)	s	2 (Vertical type)

Min. Displacement(X/Y/Z)	mm	0.001
Min. Input(X/Y/Z)	mm	0.001
Overall dimensions(Lwh)	mm	240021102800
Net weight	kg	5000
