Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > PLC Fixed-beam Planer Miller

PLC Fixed-beam Planer Miller

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

BSY

Contact Supplier Request Quote Chat Now

Shandong BSY Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shandong, China

Brand Name BSY

Model Number XKseries

Rated Power 52KW

Weight 15000KGS

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Bench(mm) 2000x1200;3000x1600;4000x1600;5000x2000;6000x2000
2.T-slot x slot width(mm) 7x28 (5x22)

1. With a fixed beam gantry structure and a solid rigidity, the machine tool is suitable for a variety of machining after the other
parts, such as universal joint, etc. are put on.
2. X, Y and Z shafts are servo driven, in which Y and Z shafts are also driven with the roller screws under control of an
electronic hand wheel. The rail is rectangular and filmed with plastic, Y shaft (horizontal) is in a slope, good in hardness
and mechanical properties.
3. The boring and cutting heads and pneumatic locking knife made in Taiwan is low in noise, but high in precision.
4. The automatic lubricating system can provide the lubricant in a fixed interval and quantity to the rails of all types.

Specification		XK
Bench	Bench(L x W)(mm)	2000x1200; 3000x1600; 4000x1600; 5000x2000;6000x2000
	T-slot x slot width(nxmm)	7x28 (5x22)
	Gauge of T-slot(mm)	200 (160)
	Vertical(mm)	850
Machining scope	Max. machining scope (mm)	2000x1400;3000x1800;4000x1800; 5000x2400;6000x2400
Machining scope	Gauge from main shaft nose to bench(mm)	150~1000
Main shaft	Bore of main shaft (KW)	N.T.NO.50
	Motor power of main shaft	11
	Revolution of main shaft(r/min)	66,90,122,182,240,330,442,660
Driving power Driving speed	Motor power of X axis(KW)	3~5
	Motor power of Y axis(KW)	2
	Motor power of Z axis(KW)	3
	Cutting and feeding speed of XY axis(mm/min)	30~2000
	Cutting and feeding speed of Z axis(mm/min)	20~2000
	Fast feeding speed of XY axis(mm/min)	4000
	Fast feeding speed of Z axis(mm/min)	3000
