Help CenterJZ40 H I BOX Beam Plate Automatic Straightening Machine h Beam Welding Machine
Related Products
-
YJZ80B H I BOX Beam Plate Hydraulic Straightening MachineUS$ 15,000 - 20,000MOQ: 1 Set -
ZHJ15 H I Beam 3 in 1 Combination Automatic Welding MachineUS$ 35,000 - 50,000MOQ: 1 Unit
-
WUXI H I BOX Beam Build up Welding Automatic h Beam Production EquipmentUS$ 50,000 - 69,900MOQ: 1 Set
-
H Beam I Beam Box Beam Automatic Submerged Arc SAW Welding DeviceUS$ 10,000 - 30,000MOQ: 1 Set
-
HW12 H I C Beam Horizontal Welding Production Line MachineryUS$ 50,000 - 100,000MOQ: 1 Set
Specifications
H I BOX Beam Plate automatic straightening Machine h beam welding machine1.Flange width: 200 - 800mm x 6-40mm, Q235
1. JZ40 H I BOX Beam Plate automatic straightening Machine technology h beam welding machine
1 |
Flange thickness |
mm |
8-40(ST37)(dependent on flange width) |
2 |
Flange width |
mm |
200-800 |
3 |
Web height |
mm |
200-1500,200-1800 |
4 |
H beam length |
mm |
4000-15000 |
5 |
Web thickness |
mm |
6-32 |
6 |
Straightening(leveling) speed |
mm/min |
13000 |
7 |
Rail length |
mm |
20000 |
2.Products of JZ40 H I BOX Beam Plate automatic straightening Machine
4.Advantage of JZ40 H I BOX Beam Plate automatic straightening Machine h beam welding machine
Easy operation, automatic welding,easy installation,lasting life
5.Machine seat and support column process of JZ40 H I BOX Beam Plate automatic straightening Machine h beam welding machine
Steel box column processed on CNC machining center, to make sure good fitting and high strength
6.Strict and serious quality testing for JZ40 H I BOX Beam Plate automatic straightening Machine h beam welding machine
There are two moving quality inspectors at each process, and the manager for each shift and monitor the production closely. Inspect and correct the parts after machining before assembling.
7.Factory and Workshop show for JZ40 H I BOX Beam Plate automatic straightening Machine
8. Package and shipment for JZ40 H I BOX Beam Plate automatic straightening Machine h beam welding machine
9. Warranty and Service after sales for JZ40 H I BOX Beam Plate automatic straightening Machine h beam welding machine
Warranty time: 12months since machinery installation finished.
Service after sales:
Professional Installation and training at customer spot factory,during time decides by different machine.
Lower price of consumable parts than markets .
Trouble response: 24hours online reply. If broken parts is not comsumable parts or breaks by wrong operation, we can send the broken parts free once confirmed.
Engineer service available overseas.
10.Application of JZ40 H I BOX Beam Plate automatic straightening Machine h beam welding machine
Cranes manufacture, steel structure manufacture,bridge building,h beam build up,automatic light h beam welding,spot welding machine, steel fabrication
